AC centrifugal air compressor for industrial
AC centrifugal air compressor for industrial, The origin of the core technology is the Kaishan R&D center in North American.These products are designed by the world-renowned expert in centrifugal compressors,Dr.Joost J.Brasz.Designed with cutting-edge technology,the 14-4PH stainless steel backeard impeller,this product features a hihg pressure surge point,a wide volume adjustment range,and high operation stability and the highest operational efficiency.
1. Superior design of the whole assembly
2. Main pump and spindle are connected by shaft coupling, so it’s convenient to replace.
3. Reliable design of sealing system to guarantee to provide 100% oil-free compressed air.
4. The design of oil system can prevent lubricated oil from polluting by surrounding environment and causing equipment downtime.
5. The inside auxiliary equipment to furthest reduce the site installations for customers.
6. Reliable & high-efficiency
7. Little vibration & low noise
8. Seft-sustained pressure lubrication system & main and auxiliary oil pumps to ensure the lubricant of gearbox.
Features of AC centrifugal air compressor for industrial
A.Economical to operate:
Due to the high efficiency of the impeller and its wide range of operation, the KCC turbo compressor uses less electricity per units of output, and is therefore less costly to operate. Additionally, the full authority controller allows the operation to be tailored to specific requirements, which in turn reduces costs.
B.Easy to control:
An easy to use interactive tough screen, operated by touch, provides all the necessary operating data. Additionally, the turbo compressor is operating with simple on/off buttons.
C.Convenient maintenance:
The KCC turbo compressor in a modular fashion which allows easy and quick access for inspection and maintenance.
D.Advanced technology assures the best performance in its components:
The specific dynamic components such as impellers and diffusers of the turbo compressor are designed to achieve optimum performance over wide operating range. They are thoroughly tested and proven in both the laboratories and fields. The turbo compressor was designed for flexibility and adaptability to meet all aspects of the customers needs.
Operation of AC centrifugal air compressor for industrial :
1. Operation environment: showing all the parameters.
2. User-friendly: using touch screen, and all related parameters could be clear at a glance.
3. Fault display features: showing the cause of the problem and giving suggestions.
4. Providing historical data
5. All the gear box, small gear bearing, big gear bearing and seal elements are using level section fraction, so it’s convenient to overhaul and maintain them by demolishing gear box cover.
6. Intercoolers are adopted the design of level tube, so more easy to clean.
7. After dismantling and reinstalling the rotor, it’s no need to make dynamic and static balance.
Please select the right style, send me the email, I will confirm you soon.
AC centrifugal air compressor for industrial :
| KCC Turbo Centrifugal Air Compressor Specification | ||||
| Model |
F.A.D. m3/min |
Working Pressure MPa |
Motor KW |
Dimension (LxWxH) mm |
| KCC100-9 | 100.0 | 0.8 | 600 | 4500×2000×3600 |
| KCC100-11 | 100.0 | 1.0 | 700 | |
| KCC120-9 | 120.0 | 0.8 | 700 | |
| KCC120-11 | 120.0 | 1.0 | 800 | |
| KCC140-9 | 140.0 | 0.8 | 900 | |
| KCC140-11 | 140.0 | 1.0 | 900 | |
| KCC160-9 | 160.0 | 0.8 | 1000 | |
| KCC160-11 | 160.0 | 1.0 | 1000 | |
| KCC180-9 | 180.0 | 0.8 | 1000 | 5000×2100×3600 |
| KCC180-11 | 180.0 | 1.0 | 1100 | |
| KCC215-9 | 215.0 | 0.8 | 1200 | |
| KCC215-11 | 215.0 | 1.0 | 1300 | |
| KCC250-9 | 250.0 | 0.8 | 1400 | |
| KCC250-11 | 250.0 | 1.0 |
1500 |
|
Usage of KaiShan KCC series AC centrifugal air compressor for industrial
1. Chemical and petrochemical process
2. Power Engineering
3. Refrigeration engineering and gas separation
4. gas delivery
There are different kinds of packing depend on what you need.
Kaishan group is a state-level large scale enterprise in China, which has been listed among the five industries of Zhejiang Provincial government, the 958 Technology Catching-up Plan and the key enterprises by Zhejiang provincial government. The group is the civilized enterprise of provincial level and contract abiding and trustworthy enterprise of state level.
Currently, Kaishan group has 18 subordinate companies with over 4100 employees. It covers an area of over 430,000 m2 with the total building complex area over 230,000 m2 and the total assets of the group amounts to over 1.5 billion.
Kaishan group has a sophisticated national-wide retail network supported by the high-quality customer service system. The nine major series of Kaishan product spread from rock drilling unit, screw air compressor to excavator, crawler drill etc, and altogether 18 categories with over 800 individual products.
By far, Kaishan group is the largest rock drill manufacturer in the world, and the largest air compressor manufacturer in China. Exports are shipped to over 20 different nations and regions such as United States, Germany, Japan, South Korea, Russia, African and Latin American countries.
