Welcome to SHAANXI KAISHAN EQUIPMENT CO.,LTD.
Best quality goods, lowest price, perfect service.
LG Water-cooled electric stationary screw air compressor
Description:
1.Air pressure: 0.7- 1.3Mpa
2.Capacity:2.3- 104M3/Min
3.Motor power scope:18.5-560KW
Characteristics:
Modulation Inlet Valve:
1.Pilot valve control 100% pressure signal to air inlet valve.
2.Modulation inlet valve to ensure energy saving.
3.Minimum pressure check valve to maintain minimum oil injection line pressure and prevent oil back flow.
High Efficient Air end:
1.Using high efficient air end
2.Special designed rotors teeth produce exceptional high quality air end
3.Reliable bearing provide extended bearing operating life.
4.Using triple shaft seal to prevent oil leakage.
5.Special designed, harden shaft seal O-ring to provide reliable shaft sealing.
Cooling system: Large cooler and larger fan allow extreme working condition.
PLC controller:
1.User friendly control panel screen
2.Easy to operate
3.Easy to read from screen
4. 24 hours remote control function
5. Show solution message when machine is malfunction
High efficient motor:
1.Large torque setting
2.F class insulation, protection grade-IP54
3.SKY bearing, low operating sound, extended operating life
4.Lubricant filler design, lubricant can be refilled when motor is in operation.
Key components
Air end
Air Cooled Package
High Efficiency Drive Motors
Integrated Microprocessor Controller
Electrical Control Protection
Versatile Package Control System
Superior Filtration System
Electronic Pressure Controller and Solenoid Valve
Technical Parameters:
Model |
Working pressure Mpa |
Capacity m3/min |
Motor Power kw |
Weight kg |
Dimension mm |
LGS-3/8 |
0.8 |
3 |
18.5 |
650 |
1260X880X1265 |
LGS-2.7/10 |
1.0 |
2.7 |
|||
LGS-2.3/13 |
1.3 |
2.3 |
|||
LGS-3.6/8 |
0.8 |
3.6 |
22 |
680 |
1260X880X1265 |
LGS-3.2/10 |
1.0 |
3.2 |
|||
LGS-2.7/13 |
1.3 |
2.7 |
|||
LGS-6.2/8G |
0.8 |
6.2 |
37 |
1020 |
1778×1000×1300 |
LGS-6.5/7 |
0.7 |
6.5 |
1550×1100×1400 |
||
LGS-6.2/8 |
0.8 |
6.2 |
|||
LGS-5.6/10 |
1.0 |
5.6 |
|||
LGS-4.8/13 |
1.3 |
4.8 |
|||
LGS-7.5/8G |
0.8 |
7.5 |
45 |
1120 |
1778×1000×1300 |
LGS-7.5/7 |
0.7 |
7.5 |
1550×1100×1400 |
||
LGS-7.5/8 |
0.8 |
7.5 |
|||
LGS-6.5/10 |
1.0 |
6.5 |
|||
LGS-5..6/13 |
1.3 |
5.6 |
|||
LGS-10/8G |
0.8 |
10 |
55 |
1580 |
1938×1160×1420 |
LGS-8.7/10 |
1.0 |
8.7 |
1630×1450×1440 |
||
LGS-7.5/13 |
1.3 |
7.5 |
|||
LGS-13/8G |
0.7 |
13 |
75 |
2000 |
2600×1350×1620 |
LGS-12/10G |
1.0 |
12 |
|||
LGS-10/10G |
1.0 |
10 |
|||
LGS-10/13 |
1.3 |
10 |
Our Company:
Shanxi Kaishan Mechanical & Electrical Equipment Co., Ltd. is located in a
1. Beautiful ancient City - Xi'an. Since founded more than 10 years ago, our company has accumulated much experience in the business of air compressors and drilling rig machines
2. National Free-inspection Product,Have passed ISO9001 certification.
3. Good Service, competitive price, high quality, fast shipping and perfect after sale service.
Workshop:
Production process:
Certificates:How to contact us?
Mobile: +86-15129884623
Tel: +86-029-88631990
Address: Room1805, Building B, Weilanguoji, Yuxiangmen, Xi'an, Shaanxi, China(Mainland)
