Help CenterHDPE Geomembrane Smooth Surface GM13 Standard Prix Geomembrane HDPE
Related Products
-
Waterproof Board HDPE GeomembraneUS$ 1.45 - 2.55MOQ: 20 Tons -
Excellent Quality Single Rough Surface HDPE Geomembrane PriceUS$ 1.45 - 2.55MOQ: 20 Tons
-
Good Price Best Quality Hdpe Pond LinerUS$ 1.45 - 2.55MOQ: 20 Tons
-
ASTM Smooth HDPE Geomembrane LinerUS$ 1.45 - 2.55MOQ: 20 Tons
-
Hdpe Geomembrane for LandfillUS$ 1.45 - 2.55MOQ: 20 Tons
Specifications
HDPE Geomembrane smooth surface GM13 standard prix geomembrane 1.Good fexibility,anti-leakage 2.anti-aging,high lor:
HDPE Geomembrane smooth surface GM13 standard prix geomembrane
Specifications:HDPE geomemebrane ,compound geomembrane,plat geomembrane seri watepoof 0.2mm-3mm,its can be widely used in water conservancy,dam,municipal administration,building,traffic,subway,tunnel etc.
It divides into one cloth one membrane,one cloth two membrane,two cloth one membrane and more cloth membrane,width 2-6m,length range is 50-100m(or at the client's request).Its can be widely used in water conservancy,dam,airport,municipal administration,building,traffic,subway,tunnel etc.
Properties:Good flexibility and the geotextile has the functions of block(anti-leakage)besides the properties of anti-aging high strength,good flexibility ,separation and antiseepage.
usage:1.prevent leakage disposal in waste burying field or waste water or waste dregs disposing field.
2.River bank,lake dam,mine remainings,reservior,tunnel,liquid,storage pool(pit mine).
3.Preventing leakage in subway,basement,tunnel,hole.
4.Anti-solt leakage in roadbed and other groundsill.
5.The plane direction laying of dam,the vertical direction laying for groundsill,used in the construction fence and waste material field.
6.Used in seawater or freshwater feed field.
7.Used in groundsill of road,highway,railway and waterproof layer of swelling clay and collapsed loess.
8.Preventing leakage on roof top .
catergory: Geomembrane including LDPE,LLDPE geomembrane,HDPE geomembrane,EVA geomembrane,ECB geomembrane,PVC geomembrane geomembrane with textured surface. catergory: Geomembrane including LDPE,LLDPE geomembrane,HDPE geomembrane,EVA geomembrane,ECB geomembrane,PVC geomembrane geomembrane with textured surface.
parameter :
| HDPE Geomembrane technical indicators GB/T | |||
| Number | Project | Index | |
| GH-1(General | GH-2(environment protection) | ||
| 1 | Tickness | 0.2-4 | |
| 2 | Width m | 2.5-8 | |
| 3 | Tensile strength (vertical and horizontal)Mpa |
≥17 | ≥25 |
| 4 | Elongation(aspect)% | ≥450 | ≥550 |
| 5 | Right angle tear strength N/mm | ≥80 | ≥110 |
| 6 | Carbon black content in% | 2.0-3.0 | 2.0-3.0 |
| 7 | Enviroment stress cracking F20,H | ≥1500 | |
| 8 | -70°C Embrittlement of low temperature impact |
Pass | |
| 9 | 200°C min oxidation induction time | ≥20 | |
| LDPE Geomembrane Specification(USA GRI-GM17 Standards) | ||||||||||
| Number | Item | Value | ||||||||
| 0.3mm | 0.5mm | 0.75mm | 1.00mm | 1.25mm | 1.50mm | 2.00mm | 2.50mm | 3.00mm | ||
| 1 | Density | 0.939 | ||||||||
| 2 | Tensile strength at break(MD/CD) | 6 | 9.5 | 14 | 19 | 23 | 28 | 37 | 47 | 56 |
| 3 | Elongation(MD/CD) | 560 | ||||||||
| 4 | Tear strength | 27 | 45 | 63 | 90 | 108 | 135 | 180 | 225 | 270 |
| 5 | Punctrue strength | 52.5 | 84 | 133 | 175 | 217 | 259 | 350 | 434 | 525 |
| 6 | Carbon black content | 2.0-3.0 | ||||||||
| 7 | Carbon black dispersion | Carbon black dispersion(only near spherical agglomerates)for 10 diffient view 9 in catagories 1or2and1 in category3 | ||||||||
| 8 | Oxidative induction time | ≥90 | ||||||||
| 9 | -70°C Low tempretrue inpact brittle property |
(Pass) | ||||||||
| 10 | Vapour permeability coefficient | ≤1.0×10-13 | ||||||||
| 11 | Dimensional stability | ±2.0 | ||||||||
