Help CenterToggle on off on
Related Products
Specifications
1.toggle on off on2.brand name:rocket
3.switch expert
chanical life 10000cycles
switch
v Potentiometer Expert since year 1967!
Company tenent: "What customer needs is our pursuit!"
Company aim: Pursue technology innovation, create green and intelligent life.
1) This guarantee does not cover damage due to misuse, abuse, neglect of alteration .
Product Type & Condition :
1. Because of the fluctuant sales situation. the stock parts are always changing and the stock list cannot be promptly updated . So,please consult the stock situation when you inquire.
Buyer Reading:
1. Please confirm receipt of products if the items you received , and if the goods was damaged please contact us immediately. send the photo to us that we can check and give you best solution .
2. We only guarantee Delivery in time but we couldn't control the express delivery time. Our related sales person will be responsible to send the AWB for the delivered goods in the next workday. you can check the AWB in the website which we send to you. For the AWB you also can call to the local branch of the express company in your company.
Item no :WH F22 A toggle on off on
Feature
1)Flux builded-up prevention is taken through inserting molding around the resistor with resin.
2)A large variety of products lined up to support various applications.
3)Miniature design for Audio applications.
4)Long life type available
Electrical characteristics
Total rotation angle :260°
Operating force :20-200gf.cm
Shaft stop strength :3kgf.cm/min
Switch working angle/stroke: 30 ±10°
Switch working torque /force:50-300gf.cm
Rated dissipation:0.125w 0.06w
Rated voltage :200V 150V
Insulation resistance :DC500V 500M Ω
Voltage proof:AC500V,1minute
Switch contact resistance:less than 20m Ω
Switch ratings:12VDC 1A
Mechanical endurance :10000cycles
Switch life:10000times
-
rated power 0.3W other 015W ing voltage 200V AC other 150V AC resistance range & tolerance 1kΩ-1MΩ ±20% resistance taper A.B.C end resistance 20Ωmax rotational noise ≤30R% rotation torque 2-55mN.m switch contack resistance 50mΩ Max switch current rating AC 250V 4A switch current rating AC 250V 4A mechanical life 10000cycles
Each carton contains two inner boxes. Each inner box has 750 pots. It has two layers and each layer has dividers, total of 25 slots on each layer. In each slot is a plastic bag with 15 pots in it. So 15 per bag per divider slot. 375 per layer, total in each inner box is 750 pcs.Grand total per box is 1500 pcs.
Size:32cm*20cm*15cm
Weight:1000pcs 6.22KG.1500pcs 9.33KG
