Home > Products > Customized Mill > Superhard micron Diamond Pulverizer/fine pulverizing powder machinery
Superhard micron Diamond Pulverizer/fine pulverizing powder machinery
- guanghzou
- T/T Credit Card
You May Like
-
superfine lithium battery powder machine grinding machine
-
Silicon Powder 15 micron pulverizer/crusher/powder smasher/high quality powder machinery
-
lithium iron phosphate LFP material grinding air jet mill chinese wholesale for battery
-
lithium carbonate Powder pulverizer high quality powder machinery
-
hot sale spherical graphite powder machinery for battery military factory supply
-
LTO material best battery making grinding air jet mill chinese wholesale
Product Details
| Condition | New | Type | Grinder | |
| Product Type | Other, food, ore, herba, etc | Place of Origin | Sichuan, China | |
| Brand Name | JSDL | Model Number | JSDLRM | |
| Voltage | 220v/380v | Power(W) | 0.75KW | |
| Dimension(L*W*H) | subject to custmer`s requests | Weight | different models different weight | |
| Certification | CE,ISO | Warranty | 12 month | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Superhard micron Diamond Pulverizer/fine pulverizing powder machinery
working principle:
the raw material is crushed by jaw crusher to the size required, then elevated into a hopper from which the material is transported through the electro-magnetic vibrating feeder evenly and continuously into the grinding chamber for powder-processing.
The rollers oscillate outward to press the ring because of the centrifugal force and the shovel scoops up the materials, send to the middle between the ring and rollers to accomplish the grinding.After grinding, the rough materials will be recycled by the air from the fan back into the grinding chamber for regrinding and the fine powders are blew into the cyclone and poured out through the output-powder pipe as the final products.
1. High efficiency and low energy consumption.
2. Accept different raw material size.
3. Dust extraction is up to the national relative standard.
4. Good stability and free from noisy pollution.
5. Good sealability.
well done powders:
techinical data:
Type/data/name | JS1410 | JS2115 | JS2615 | JS2715 | JS3016 | JS3216 | JS4116 |
Max feed size | 10-15 | 10-20 | 10-20 | 10-20 | 10-25 | 20-25 | 20-30 |
Raw material size | 0.125-0.044 | ||||||
Gross output(T) | 0.5-8 | 1-18 | 1.5-20 | 2-28 | 3-35 | 6-50 | 6-66 |
Center shift speed(r/min) | 280 | 160 | 162 | 162 | 160 | 140 | 103 |
Inner diameter of grinding ring(mm) | 435 | 630 | 780 | 820 | 910 | 970 | 1280 |
Mainframe power(kw) | 7.5/6 | 15/8 | 18.5/8 | 22/8 | 30/8 | 37/4 | 75/4 |
Fan power(kw) | 5.5/2 | 11/4 | 15/4 | 1835/4 | 22/4 | 30/4 | 55/4 |
Analyzer power(kw) | 1.1/2 | 2.2/6 | 2.2/6 | 2.2/6 | 2.2/6 | 5.5/4 | 7.5/4 |
we have professional sales team for pre-sales and after-sales services, also we will send engineer to your factory if you need.
We believe that our perfect products and excellent services will establish a win-win business relationship with you.
Chengdu Our Trading Co.,Ltd is a trade and industry integrated company which established in 2008 with abundant exporting experience. With the company developed, we have 2 factories, one is located in Chengdu and another is in Mianyang.
Our main products are micronizer jet mill, micronizer impact mill, air classifier, inter gas protective equipmentetc.
patent:
workshop:
website:
tel: 028-61318297
Skype: wu.yao5
welcome to contact me at anytime !
