Transmitter

Name: Transmitter
Brand: Ambetronics
SKU: 130070945
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Maharashtra, India

Brand Name:

Ambetronics

Model Number:

TRH 511

Ambetronics Engineers Private Limited

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Mumbai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Maharashtra, India

Brand Name Ambetronics

Model Number TRH 511

Usage Industrial

Theory Temperature Transmitter

Specifications

Flameproof version is available on request for hazardous application

Transmitter

FEATURES:

Based on state of art latest microcontroller technology with Watchdog feature for fail safe operation
Highly accurate, fast & reliable sensing technology
Fixed resolution of 0.1 for both Temperature & Relative humidity
Long term Stability for %RH is typically < 1% RH / year
Isolated RS485 Serial port with MODBUS RTU Protocol output for PC interface
Two freely scalable & configurable analog output
Flameproof version is available on request for hazardous application
Excellent long term stability
Compact size, easy to install & flexible
Optional display / keypad.

APPLICATIONS:

Building automation, climate control rooms, computer server rooms, green houses.
Agriculture application, meteorological application, weather station.
Humidifiers & Dehumidifiers, electronic enclosure.
Drying process in chemical application.
Storage room monitoring, cold storage, clean rooms, warehouse.
Pharmaceuticals, Medical application (health care, medicine storage).
Calibration equipment.
Industrial process monitoring & controls & etc.

TECHNICAL SPECIFICATIONS
Sensor Type	1) Polymer sensing for Temperature, 2) Capacity polymer sensing for Relative humidity.
Range	1)0 to 50^oC typical for Temperature (Range of 0 to 50^oC available with sensor probe with 1meter cable length.) 2)10 to 95%RH is typical for Relative humidity.
Resolution	Fixed 0.1 for both Temperature & Relative humidity.
Accuracy	1)Ã‚Â±0.5^oC for 0 to 50^oC for Temperature. 2)Ã‚Â±1.8% for 10 to 95% RH for Relative humidity, Long term Stability for %RH is typically < 1% RH / year.
Display	1) Without display, 2) With LCD Display with backlit (optional). 8 display indication for Temperature, 8 display indication for Relative humidity.
Setting	By 4 keys on front panel i.e. Keys. (Optional)
Supply Voltage	24VDC / 150mA.
Mounting	Wall mounting / Pipe Mounting for Flameproof Model
Sensor Housing	PVC material OR TEFLON material (Length 85mm.) / SS304 / SS316
Cable Entry	1 number of thermoplastic cable gland (IP-68) with clamping range of 2.5 to 6.5mm. for four core cable.
Dimension	80 (W) X 120 (H) X 55 (D) in mm.
Cabinet	ABS (IP65) Enclosure.
Optional	a)Isolated RS485 Serial port with MODBUS RTU Protocol output for PC interface. b) Two freely scalable & configurable analog output ( 4 - 20mA). c) Flameproof version is available on request for hazardous application.
Weight	1Kg
