Product Details
Condition: | New | Type: | Other, induction heater | Power Source: | Electric |
Place of Origin: | Henan, China | Brand Name: | Yongda | Model Number: | WZP-160 |
Voltage: | 320-420V | Power(W): | 90KW | Certification: | ISO CE |
Warranty: | one year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Heat exchanger for induction heating machine cooling
We mainly produce induction heating machine , used for metal heating, heat treating, forging, brazing,annealing,melting etc.
Detailed applications of induction heating machine
1. Brazing categories:
1.1 welding diamond saw blade, carbide saw blade welding and diamond cutting tools, grinding tools, drilling welding.
1.2 carbide cutting tools for machining welding. Such as turning, milling cutter welding.
1.3 mining tools, welding, such as "one" bits, pillar gear drill bits, dovetail coal drill bits, drill rods riveting, all kinds of shearer, a variety of shearer, boring machine pick a variety of welding.
1.4 The welding of various wood working tools, such as various woodworking planer, milling, and welding a variety of woodworking drill.
2. Forging, rolling class
2.1 The variety of hot-rolled twist drill.
2.2 standard parts, hot forging fasteners, such as high strength bolts, nuts and so on.
2.3 drill steel, tempering brazing, forging, extrusion heating.
3. Heat treatment Class
3.1 The various hardware tools, hand tools, heat treatment. Such as pliers, wrenches, screwdrivers, hammers, axes and so on.
3.2 kinds of auto parts, motorcycle accessories high-frequency quenching. Such as: crankshaft, connecting rod, piston pin, crank pin, wheel, camshaft, valves, all kinds of rocker arm, rocker shaft; transmission of various gears, spline shafts, drive axle, a variety of small axes, a variety of fork and other high-frequency quenching.
3.3 power tools on the gears, shafts and other high-frequency quenching.
3.4 a variety of hydraulic components, pneumatic components of high frequency hardening heat treatment. Such as the piston plunger, rotor pump rotor on a variety of valves for the shaft, the gear pump gear, etc. quenching.
3.5 Heat treatment of metal parts. Such as the various gears, sprockets, all kinds of shafts, spline shafts, pins and other high-frequency quenching.
3.6 Machine tool industry guide, tools swallowtail quenching treatment.
4. Other
Such as precious metals smelting. Such as melting gold, silver, etc.
Features : Unique water circulating system make machine can work 24 hours continuously .
heat exchanger
Technical parameters of heat exchanger
Model | YD-300-4.0 | YD-300-7.5 |
Cooling capacity | 10T | 15T |
Water flow | 10 m3/h | 15 m3/h |
Power of water pump | 4.0KW | 7.5KW |
Water capacity of tank | 250L | 400L |
Outside diameter of outlet cooling water | DN40(Quick coupler) | DN65(Flange) |
Dimension | 1300× 870× 930 (mm) | 1550× 1000× 1050 (mm) |
Noise | ≤70 dB(A) | ≤70 dB(A) |
Ambient temperature | 8~40℃ | 8~40℃ |
Induction heating machine WZP-120
Technical parameters of WZP-160 induction heating machine
Model: WZP-160 |
Composition: WZP-160 induction generator 1 piece WZP-160 transformer 1 piece |
Input voltage (DC) | 70-550V |
Input Voltage (AC) | three phases 380V ±20% 50-60HZ |
Input current | 6-160A |
Input power | 10-90kw (power adjustable) |
Oscillation frequency | 8-30KHZ |
Continuous load rate | 100% |
Work time | 24 hours of continuous working |
Cooling water pressure | 0.3MPA |
Size (L*W*H) | Generator 665×400×790mm Transformer 660×400×380mm |
Weight | Generator 65KG Transformer 70KG |
Accessories | +Induction coils 2 pieces +Foot switch 1 piece +Water shunt valve 1 piece +Water hose(standard configuration) +User manual 1 piece |
Features of induction heating machine
1, a unique cooling circulation system, ensure that the equipment 24 hours of continuous work.
2,full range, high frequency, super audio frequency series, Type 40,60,90,120,160,200,300,400,500.
3, small size, light weight, simple installation, easy to operate;
4, high efficiency, energy saving is very obvious, saving 60% energy than traditional high frequency tube equipment, and saving 20% energy compared with SCR-IF induction furnace.
5, safe, reliable, no million-volt high-pressure, very safe for the operator;
6, almost no oxide layer, produced no exhaust, no wastewater is generated.
7, the frequency bandwidth to meet the different parts of the heating before forging, heat treatment, brazing and so on.
