Home > Products > Induction Melting > China wholesale cheap steel scrap melting induction furnace
China wholesale cheap steel scrap melting induction furnace
- 500 Set / Sets per Month
- Shanghai Qingdao Tianjin Guangzhou or as you request
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Type: | Induction Furnace | Usage: | Other, Melting Furnace, smelting silver,gold,Copper etc. |
Place of Origin: | Henan, China | Brand Name: | Yongda | Model Number: | WZP-15 |
Voltage: | 180-240V | Power(W): | 15KW | Dimension(L*W*H): | 410*200*420mm |
Weight: | 28kgs | Certification: | ISO9001 | Warranty: | 12 months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
China wholesale cheap steel scrap melting induction furnace
Model | Steel and stainless steel | Gold, silver, copper | Aluminum |
WZP-15 | ----- | 10kg | 3kg |
WZP-25 | 5kg | 20kg | 6kg |
WZP-35 | 10kg | 30kg | 10kg |
WZP-45 | 18kg | 50kg | 20kg |
WZP-70 | 25kg | 100kg | 30kg |
WZP-90 | 40kg | 120kg | 40kg |
WZP-110 | 50kg | 150kg | 50kg |
WZP-160 | 100kg | 250kg | 100kg |
WZP-300 | 200kg | 500kg | 200kg |
Application | Definition | Scope of application | Selection of frequency | Selection of power |
Melting | Heating metals in a non-conductive crucible to enable the metal being melted down to liquid form. | Melting of gold, silver, copper, aluminium , semiconducting materials,etc. | Selection of frequency depends on capacity of furnace. The capacity is smaller,the frequency is higher, the capacity is bigger,the frequency is lower. | The power depends on the weight of melted metal and melting time for one furnace |
Packing:
Two wooden cases (plywood) Inside,will be filled with plastic foam,for waterproof and shockproof.
Accessories: induction coils,foot switch and installing and operating instructions
Shipping: by sea LCL(less than container load) or by air.
First, quenching categories:
1. All kinds of gears, sprockets, shaft quenching;
2. a variety of axle, leaf springs, fork, valve, rocker, ball stud and other auto parts quenching.
3. All kinds of engine parts, gear parts hardened surface;
4 bed machine tool of machine tool industry guide of quenching (lathe, milling machine, planer, punch, etc.).
5. All kinds of pliers, knives, scissors, axes, hammers and other hand tools quenching.
Second, Diathermy categories:
1. All kinds of bolt, nut hot forging;
2 hot-rolled cannabis cobalt;
3 diameter of 50 within all parts through hot forging;
Third, welding class:
1 piece of diamond drill bit composite welding;
2 of carbide blade, saw blade welding;
3. All kinds of cutter, drill head, drill pipe, coal drill bits, drill bits and other mine parts of the wind welding;
Successfully Case Study:
1 Shaft hardened, hardened layer of 1.5-3mm, diameter Φ10mm-250mm, bore all kinds of quenching.
2. Φ5-Φ12 wire annealing.
3 Drill head welding.
4. Φ25 bar through the following heat, the speed is much faster than the SCR. Φ60mm-Φ100mm bar diathermy
5 kinds of chains, sprockets heat treatment
6. Angang 3 meters in diameter hardened gear weight 80 tons
7. Hanjiang River Bridge with Φ1016mm thickness 17.5mm steel heated to 1,000 degrees bending shape.
8. Necking forming various types of pipe heating
9. Copper annealing, wire annealing
10. Machine Tool Gears, Sprockets quenching
11. kinds of heat flared elbow necking.
12. Φ50mm 3mm thick stainless steel annealing
FAQ:
What’s your MOQ? | Any quantity of machine will be accepted. MOQ:1 Set |
Which place your factory is located? | We are located in Shenqiu County, Zhoukou city, Henan Province ,China |
How far from Beijing? I think it is more closer to Shanghai | Our factory is near both and Shanghai. We have office in Zhengzhou, we can pick up you at Zhengzhou CGO airport,and then to our factory via expressway about two hours. |
We need to see some more videos for production line and also pictures of your factory, water drawing and panel drawing | Well, we have many videos show our customer’s machine working scene(Various of applications: forging, hardening, brazing, shrink fitting, melting and hot coating etc. According to your work piece processing requirements,) send you the corresponding video link or send by email.2. Yes, we can provide you factory pictures and machine water connection and control panel details. |
Do you have quality certifications? | Yes, we got the ISO9001:2000 International quality management system certification in August,2001, |
How do you packing the machines? | Standard export wooden cases(plywood) Usually every set machine will be used two wooden cases: one for packing induction heating generator, one for packing transformer. Inside will be filled with plastic foam for waterproof and shockproof |
More questions….? | Updating… |
Shenqiu Yongda High Frequency Equipment Co., Ltd. was founded in 1996, which belongs to high-tech enterprise in Henan Province,China. We are located in Shenqiu County, Zhoukou City. We professionally dedicated to Research & Development,production of high frequency induction heating machine, medium frequency induction heating equipment,supersonic frequency induction heating machine,induction forging machine, induction hardening machine, adhering to the spirit of innovation, mean while strengthening cooperation with domestic well-known universities and research institutions. We are the leader of domestic induction heating field, and got the ISO9001:2000 international quality management system certification in August, 2004. Up to now, we has 83 office in domestic ,products hot sale , and also exported to Europe,America,and Southeast Asia etc. other regions. We have international trade office in zhengzhou. East to international airport (CGO), besides, high way, high speed rail,transport is very convenient.
Company products:
Medium frequency induction heating machine IGBT and KGPS SCR
High frequency (Super audio ) induction heating machine
Induction hardening machine, induction forging machine,induction brazing machine, induction annealing furnace,
Electromagnetic induction heating equipment,Induction melting furnace ;
CNC hardening machine tool,Automatic feeding steel rods machine,
Round bar,steel pipe induction hardening and tempering equipment
Concrete pump pipe dedicated quenching machine,Hydraulic cylinder cladding equipment;
Closed cooling tower,etc.
Products applications:
Metal forging,hardening,brazing, annealing, melting,shrink fit, thermal compound,plastic machine screw cylinder heating etc. other fields.
Corporate Culture
Quality goal: Zero annual customer complaint rate
Quality policy: Scientific management, pursuing excellence, elaborate and perfect works.
Quality concept: Product quality and the future of Yongda are controlled by us.We will make every efforts let Yongda quality arrive perfection , based on strict and efficient attitude .
Service concept: Customer is in my heart. What users need, what Yongda provides.We will take real actions to solve problems for customers.
Good faith: The people who are honest will possess real friend. The enterprise that is in good faith will make long-term development.
Innovation: Innovation is the driving force for enterprise development. Without innovation there would be no rapid development for enterprises.
Sincerely welcome customers at home and abroad to visit us and negotiation business !
Address: NO.65,Liufu town economic and technical development,Shenqiu County, Zhoukou,Henan, China
