Top Selling induction melting furnace for sale from Yongda Co.
- 500 Set / Sets per Month
- Shanghai Qingdao Tianjin Guangzhou or as you request
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Type: | Induction Furnace | Usage: | Melting Furnace |
Place of Origin: | Henan, China | Brand Name: | yongda | Model Number: | WZP-160 |
Voltage: | 380V+/-10% | Power(W): | 160KW | Weight: | 300kgs |
Certification: | ISO9001 | Warranty: | 12 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Top Selling induction melting furnace for sale from Yongda Co.
Melting material
My company produced induction melting furnace is used for melting copper,aluminum,gold,silver,zinc,nickle etc. Medium frequency induction melting furnace is used for melting steel, stainless steel,copper,aluminum ,gold and silver etc. other material.
Features of induction melting furnace
1. Medium frequency melting furnace has good electromagnetic stirring ,melting metal in favor of a uniform temperature and organizations ,in favor of scum and reduce inpurities.
2. Wide frequency range,from 1KHZ to 20KHZ,be considering the amount of melting,electromagnetic stirring,heating efficiency,noise at work and other factors to design induction coils and equipped with compensation capacitor ,determine the output frequency
3. Save at least above 20% energy than SCR medium frequency device.
4. Machines has small size,light weight,melting capacity is from a few kilograms to hundreds of kilograms,a large range to choose,both for factory use, can also used for schools and institutes, a small amount of melting.
Technical parametes of induction melting furnace
Model | Steel and stainless steel | Gold, silver, copper | Aluminum |
WZP-15 | ----- | 10kg | 3kg |
WZP-25 | 5kg | 20kg | 6kg |
WZP-35 | 10kg | 30kg | 10kg |
WZP-45 | 18kg | 50kg | 20kg |
WZP-70 | 25kg | 100kg | 30kg |
WZP-90 | 40kg | 120kg | 40kg |
WZP-110 | 50kg | 150kg | 50kg |
WZP-160 | 100kg | 250kg | 100kg |
WZP-300 | 200kg | 500kg | 200kg |
1. ultra-small type medium frequency induction heating power supply
2, the ejection type or tilting type melting furnace
3, the compensation capacitor box
Advantages of induction melting furnace
1, the device is small, light weight, high efficiency, low power consumption;
2, around the furnace temperature is low, less dust, good working environment;
3, the operation process is simple, melting running reliable;
4, the heating temperature, less burning, metal composition uniformity, good casting quality;
5, melting fast heating, temperature and easy control, high production efficiency besides,our product has got Quality System Certificate, utility model and design patent.
Pictures of induction melting furnace
1. Reply your inquiry within 24 working hours
2. Experienced engineer instruct and sales communicate with you in fluent English.
3. According to work pieces specifications, heating requirements, propose best solutions,also reference your ideas.
4. Machine details and working video link for your reference
5. Competitive price ,compare with the same industry
6. Production: strict quality standard, to produce machine and induction coils.
7. Debugging machine and only good machine will be sent.
8. Tracking goods shipping and provide bill of lading,invoice,packing list and other documents what you need
9. Provide install and technology instruction by sending drawings, email, or telephone,video.
10.If you need, will arrange one engineer to your place,instruct install machine and training operators.
11.Excess warranty period(12 months warranty), you can buy the spare parts from us with special discount price.
12.Provide long-terms technical support.
Custorm visit our factory
Yongda Brand induction melting furnace has high quality,low price.
Welcome to inquiry or chat online ,make a phonecall to discuss business !
