Specifications
induction heating power supply1. advanced igbt technology
2. industrial heating machine
3. work stable
4. enery save
Most popular WZP-65KW induction heating power supply
Industrial induction heating power : is mainly used for heating metal work pieces.
Application ranges:
1, through thermoforming all kinds of standard parts, fasteners, machinery parts, hardware tools, straight shank twist drill of hot forging, hot rolling, metal annealing. Such as: tensile steel; wire, nail wire heating; stainless steel annealed, rose type.
2, heat treatment various types of hardware tools, electric, hydraulic, pneumatic components, automotive, motorcycle parts and other mechanical parts of the surface of the metal, the hole, partial or total quenching. Such as: hammer, knife, scissors, pliers and all kinds of shafts, cams, sprockets, gears, valves, ball stud, a large machine tool guide, ductile iron quenching.
3, various types of brazing carbide blade, turning, milling, planing, reamer, diamond saw blade, serrated welding; grinding, drilling, cutting welding; brass, copper, stainless steel pot, etc. hybrid welding of metallic materials.
4, metal melting: melting gold, silver and copper.
5, other areas of plastic pipe heating cable, heating wire coating; food, beverage, pharmaceutical industry, the use of aluminum foil.
Product features:
1, small size, light weight, easy installation, easy operation.
2, high efficiency, saving energy obviously, high-frequency energy-saving equipment than the traditional 60%
3, safe and reliable, no million-volt high-pressure, very safe for the operator.
4, the frequency bandwidth to meet the different parts of brazing, heat treatment, forging before heating.
5, a unique cooling system, ensure that the equipment 24 hours of continuous work.
Induction Heating power supply used for bolts ends forging
Main technial parameters of WZP-65KW induction heating power supply
| Model | WZP-65 |
| Work power | 3 phase 380V+/-10%, 50-60HZ |
| Input voltage | 320V-420V can be changed, depend on your country's electric power |
| Input current | 6-120A |
| Input power | 3-65KW adjustable stepless |
| Oscillation frequency | 15-30KHZ also can be changed, depend on your work pieces size |
| Size of generator | 665*400*730mm |
| Size of transformer | 660*490*435mm |
| Weight of generator | 48kgs |
| Weight of transformer | 66kgs |
| Cooling water pressure | 0.3 MPA |
Pictures of induction heater machine and its application
Metal work piece showroom: all work parts are processed by our induction heating machine
Induction coils ,suitable for bars forging
1. Reply your inquiry within 24 working hours
2. Experienced engineer instruct and sales communicate with you in fluent English.
3. According to work pieces specifications, heating requirements, propose best solutions,also reference your ideas.
4. Machine details and working video link for your reference
5. Competitive price ,compare with the same industry
6. Production: strict quality standard, to produce machine and induction coils.
7. Debugging machine and only good machine will be sent.
8. Tracking goods shipping and provide bill of lading,invoice,packing list and other documents what you need
9. Provide install and technology instruction by sending drawings, email, or telephone,video.
10.If you need, will arrange one engineer to your place,instruct install machine and training operators.
11.Excess warranty period(12 months warranty), you can buy the spare parts from us with special discount price.
12.Provide long-terms technical support
Packing for induction heating power supply
1.Two wooden cases (plywood) Inside,will be filled with plastic foam,for waterproof and shockproof.
2.Accessories: induction coils,foot switch and installing and operating instructions
3. Packing size: generator 830*500*880 transformer 830*600*550mm
Shipping: by sea LCL(less than container load) or by air.
What’s your MOQ? | Any quantity of machine will be accepted. MOQ:1 Set |
Which place your factory is located? | We are located in Shenqiu County, Zhoukou city, Henan Province ,China |
How far from Beijing? I think it is more closer to Shanghai | Our factory is near both and Shanghai. We have office in Zhengzhou, we can pick up you at Zhengzhou CGO airport,and then to our factory via expressway about two hours. |
We need to see some more videos for production line and also pictures of your factory, water drawing and panel drawing | Well, we have many videos show our customer’s machine working scene(Various of applications: forging,hardening, brazing, shrink fitting, melting and hot coating etc. According to your work piece processing requirements,) send you the corresponding video link or send by email. 2. Yes, we can provide you factory pictures and machine water connection and control panel details. |
Do you have quality certifications? | Yes, we got the ISO9001:2000 International quality management system certification in August,2001, |
How do you packing the machines? | Standard export wooden cases(plywood) Usually every set machine will be used two wooden cases: one for packing induction heating generator, one for packing transformer. Inside will be filled with plastic foam for waterproof and shockproof |
More questions….? | Updating… |
Shenqiu Yongda High Frequency Equipment Co., Ltd. was founded in 1996, which belongs to high-tech enterprise in Henan Province,China. We are located in Shenqiu County, Zhoukou City. We professionally dedicated to R&D,production of HF,SSF,MF induction heating equipment,induction heating power supply,adhering to the spirit of innovation, mean while strengthening cooperation with domestic well-known universities and research institutions. We are the leader of domestic induction heating field, and got the ISO9001:2000 international quality management system certification in August, 2004. Up to now, we has 83 office in domestic ,products hot sale , and also exported to Europe,America,and Southeast Asia etc. other regions.
Professional induction heating power manfuacturer, Shenqiu Yongda - since 1996
Thanks for your reading ! Welcome to contact us !
