High frequency induction heating power supply
Advantages of Yongda high frequencyinduction heating power supply
1.High efficient: energy saving,environmental protection
2.Heating fast:The fastest heating speed is less than 1 second
3.Heating wide: can heating variety of metal workpieces(according to different shapes of work pieces, replace removable induction coils)
4.Start fast, pass water and electric power can start heating
5.Low power consumption:can save about 40% energy than tradional HF tube furnace , save degree is relation with shpes of work pieces and induction coils
6.High security, eliminating the nearly million-Volt high voltage
7.Full protection: has over voltage,over current,temperature is over high,lack of water, lack of phase,etc, alarm lamps indicators. can automaticly control and protection the machine itself.
Technial parameters of Yongda high frequency induction heating power supply
| Model | Input Voltage | Input Current | Oscillation frequency | Cooling water pressure |
| WGH-IV-16 | single phase 220V | 3-30A | 30-50KHZ | 0.1-0.3MPA |
| WGH-IV-36 | three-phase 380V | 3-36A | 30-40KHZ | 0.1-0.3MPA |
| WGH-V-50 | three-phase 380V | 3-50A | 30-35KHZ | 0.1-0.3MPA |
| WGH-V-60 | three-phase 380V | 6-60A | 30-35KHZ | 0.1-0.3MPA |
| WGH-VI-80 | three-phase 380V | 6-80A | 25-35KHZ | 0.1-0.3MPA |
| WGH-VI-120 | three-phase 380V | 6-120A | 20-30KHZ | 0.1-0.3MPA |
| WGH-VI-160 | three-phase 380V | 6-160A | 20-30KHZ | 0.1-0.3MPA |
The application of Yongda high frequency induction heating power supply
1.through thermoforming all kinds of standard parts, fasteners, machinery parts, hardware tools, straight shank twist drill of hot forging, hot rolling, metal annealing. Such as: tensile steel; wire, nail wire heating; stainless steel annealed, rose type.
2.heat treatment various types of hardware tools, electric, hydraulic, pneumatic components, automotive, motorcycle parts and other mechanical parts of the surface of the metal, the hole, partial or total quenching. Such as: hammer, knife, scissors, pliers and all kinds of shafts, cams, sprockets, gears, valves, ball stud, a large machine tool guide, ductile iron quenching.
3.various types of brazing carbide blade, turning, milling, planing, reamer, diamond saw blade, serrated welding; grinding, drilling, cutting welding; brass, copper, stainless steel pot, etc. hybrid welding of metallic materials.
tal melting: melting gold, silver and copper.
5.other areas of plastic pipe heating cable, heating wire coating; food, beverage, pharmaceutical industry, the use of aluminum foil.
Product quality certificatioins: ISO9001-2000
Packing high frequency induction heating power supply:
Two wooden cases (plywood) Inside,will be filled with plastic foam,for waterproof and shockproof.
Accessories: induction coils,foot switch and installing and operating instructions
Shipping: by sea LCL(less than container load) or by air.
1. Reply your inquiry within 24 working hours
2. Experienced engineer instruct and sales communicate with you in fluent English.
3. According to work pieces specifications, heating requirements, propose best solutions,also reference your ideas.
4. Machine details and working video link for your reference
5. Competitive price ,compare with the same industry
6. Production: strict quality standard, to produce machine and induction coils.
7. Debugging machine and only good machine will be sent.
8. Tracking goods shipping and provide bill of lading,invoice,packing list and other documents what you need
9. Provide install and technology instruction by sending drawings, email, or telephone,video.
10.If you need, will arrange one engineer to your place,instruct install machine and training operators.
11.Excess warranty period(12 months warranty), you can buy the spare parts from us with special discount price.
12.Provide long-terms technical support.
Good faith enterprice honor certifications
| What’s your MOQ? | Any quantity of machine will be accepted. MOQ:1 Set |
| Which place your factory is located? | We are located in Shenqiu County, Zhoukou city, Henan Province ,China |
| How far from Beijing? I think it is more closer to Shanghai | Our factory is near both and Shanghai. We have office in Zhengzhou, we can pick up you at Zhengzhou CGO airport,and then to our factory via expressway about two hours. |
| We need to see some more videos for production line and also pictures of your factory, water drawing and panel drawing | Well, we have many videos show our customer’s machine working scene(Various of applications: forging,hardening, brazing, shrink fitting, melting and hot coating etc. According to your work piece processing requirements,) send you the corresponding video link or send by email. 2. Yes, we can provide you factory pictures and machine water connection and control panel details. |
| Do you have quality certifications? | Yes, we got the ISO9001:2000 International quality management system certification in August,2001, |
| How do you packing the machines? | Standard export wooden cases(plywood) Usually every set machine will be used two wooden cases: one for packing induction heating generator, one for packing transformer. Inside will be filled with plastic foam for waterproof and shockproof |
| More questions….? | Updating… |
Thanks for your reading ! Welcome to contact us !
