Specifications
steel hot forging machine1. adopts igbt modules
2. eco-friendly
3. easy operation
4. low cost
Manufacturer direct sale steel hot forging machine
Power: 15KW-500KW IGBT induction steel hot forging machine : High frequency, supersonic and medium frequency induction heating power supply .
Different models and parameters
Model |
Input voltage |
Input current |
Oscillation frequency |
Cooling water pressure |
WZP-40 |
320-420V |
2-40A |
15-30KHZ |
0.1MPA |
WZP-60 |
320-420V |
3-60A |
15-30KHZ |
0.2MPA |
WZP-90 |
320-420V |
4-90A |
15-30KHZ |
0.3MPA |
WZP-120 |
320-420V |
6-120A |
15-30KHZ |
0.3MPA |
WZP-160 |
320-420V |
6-160A |
15-30KHZ |
0.3MPA |
WZP-200 |
320-420V |
6-200A |
15-30KHZ |
0.3MPA |
WZP-300 |
320-420V |
6-300A |
15-30KHZ |
0.3MPA |
WZP-400 |
320-420V |
6-400A |
8-15KHZ |
0.3MPA |
WZP-500 |
320-420V |
6-500A |
8-15KHZ |
0.3MPA |
Usage of steel forging machine:
Hand tools hot forging
Steel rods , round or square steel forging
Copper rods hot forging
Steel plate hot forging
Flange forging
Diameter 10-40mm, suggestion supersonic frequency
Diameter 40-70mm, IGBT medium frequency forging furnace
Diameter 70-121mm, suggest KGPS scr MF induction forging machine
This is not the final factor to decide which model is suitable for your job, welcome customers to tell us more details about size of work pieces and applications. Thanks for your cooperation !
Steel rod hot forging
Manual feeding steel bar hot forging machine
Autuomatic feeding bars hot forging machine
Steel plate hot forging
Oversea customers visit us .
We are in induction heating exhibition
Packing for stel hot forging machine
1.Wooden cases (plywood) or carton, as you required.
2.Inside,will be filled with plastic foam,for waterproof and shockproof.
3.Accessories: induction coils,foot switch and installing and operating instructions
Shipping: by sea LCL(less than container load) or by air/train/courier
Thanks for your reading, welcome to contact Jessie at any time !
