Specifications
ultrasonic induction heating machine1. adopts igbt modules
2. metal heated
3. easy to change coils
4. low cost
Wooden cases packed sea transport ultrasonic induction heating machine
About ultrasonic induction heating machine
Frequency: 10-50KHZ
Power: 16kw,36kw,45kw,65kw,85kw,120kw,160kw,200kw,260KW ,power adjustable stepless
Series: WZP Series
Brand: Yongda
Manufacturer: Shenqiu Yongda HF Equipment Co.,Ltd
Usage: heating metal, forging, hardening, brazing,annealing,melting,shrink fitting, hot coating etc.
Different models and parameters
Model |
Input voltage |
Input current |
Oscillation frequency |
Cooling water pressure |
WZP-40 |
320-420V |
2-40A |
15-30KHZ |
0.1MPA |
WZP-60 |
320-420V |
3-60A |
15-30KHZ |
0.2MPA |
WZP-90 |
320-420V |
4-90A |
15-30KHZ |
0.3MPA |
WZP-120 |
320-420V |
6-120A |
15-30KHZ |
0.3MPA |
WZP-160 |
320-420V |
6-160A |
15-30KHZ |
0.3MPA |
WZP-200 |
320-420V |
6-200A |
15-30KHZ |
0.3MPA |
WZP-300 |
320-420V |
6-300A |
15-30KHZ |
0.3MPA |
WZP-400 |
320-420V |
6-400A |
8-15KHZ |
0.3MPA |
WZP-500 |
320-420V |
6-500A |
8-15KHZ |
0.3MPA |
Ultrasonic induction heating machine has two parts: generator and transformer
Applications
1, Induction forging
A, all kinds of standard parts, fasteners, machinery parts, hardware tools, straight shank twist hot upsetting, hot.
B, metal heat annealing. Such as: tensile steel tube, pipe, smashed head; wire, heating wire nail; stainless steel annealed, rose type.
Standard parts hot forging
2, Induction hardening
Various types of hardware, electrical, hydraulic, pneumatic components, automobiles, and motorcycle parts and other mechanical parts of the surface of the metal, bore, in part or in whole quenching. Such as: hammer, knife, scissors, pliers and various types of shafts, cams, sprockets, gears, valves, ball pin, large-scale Machine Tool, ductile iron quenching.
Machine tool guide rail hardening
3, Induction brazing
Various types of carbide blades, turning, milling, planer, reamer, diamond saw blade, saw welding; grinding, drilling, cutting welding; brass, copper, stainless steel and other metal materials, the composite bottom of the pot Welding.
4, metal melting: melting gold, silver and copper.
5, the other heated areas
Plastic pipe, cable, wire heating film; food, beverage, pharmaceutical industry uses aluminum foil.
Oversea customers visit us .
Packing for ultrasonic induction heating machine
1.Wooden cases (plywood) or carton, as you required.
2.Inside,will be filled with plastic foam,for waterproof and shockproof.
3.Accessories: induction coils,foot switch and installing and operating instructions
Shipping: by sea LCL(less than container load) or by air/train/courier
2. Recommend suitable machine model,according to your work piece specifications and heating requirements.
3. Send detailed product parameters, photos and price.
4. Solve all the problem , such as shipping cost, shipping time,delivery time, warranty etc,what you concerned.
5. Reach an agreements, sign proforma invoice or contract.
6. Produce induction heating equipment strictly based on the PI/contract.
7. Arrange goods shipment
8.Tracking goods and help you install and operating machines.
9. Email or Call visit.
10.Provide long-terms technical support.
