Plastic Drainage/gas/water Supply PVC Pipe Making Machines
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Pipe Production Line
Pipe Material:
PVC
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Single Wall PP Pipe Corrugated Pipe ExtruderNegotiableMOQ: 1 Set -
PVC PE Single Wall Corrugated Tube Forming MachineNegotiableMOQ: 1 Set
-
Single Wall PP Corrugated Pipe Production LineNegotiableMOQ: 1 Set
-
PP/PE/ABS Sheet Extrusion Line,sheet Extrusion MachineNegotiableMOQ: 1 Set
-
Double-Wall Corrugated Pipe Extrusion LineUS$ 20,000 - 30,000MOQ: 1 Set
Condition
New
Type
Pipe Production Line
Pipe Material
PVC
Application
Drain Pipe
Place of Origin
Jiangsu, China
Brand Name
gerui
After-sales Service Provided
Engineers available to service machinery overseas
Machine: Plastic drainage/gas/water supply PVC pipe making machines
Introduction:
This series extruders with different screws, dies and other auxiliaries can directly convert thermoplastic expecially PVC powders into pipe, sheet, film, and profile; also it can modify and granulate.
Technical Parameter (FYI):
| Model number | Screw diameter (mm) | Rotational speed of screw (rpm) | Effective work length (mm) | Main motor power (kw) | Heating power of Barrel (kw) | Production capacity (kg/h) | Central height of machine (mm) | Net weight | Overall size (mm) |
| SJSZ45 | 45/90 | 1-45 | 1070 | 15 | 9.6 | 70 | 1000 | 2800 | 3300*1200*2000 |
| SJSZ51 | 51/105 | 1-45.5 | 1100 | 22 | 11.5 | 80 | 1000 | 3000 | 3360*1290*2100 |
| SJSZ55 | 55/110 | 1-40 | 1200 | 22 | 18 | 150 | 1000 | 3500 | 3620*1350*2200 |
| SJSZ65 | 65/132 | 1-38 | 1440 | 37 | 24 | 250 | 1000 | 4000 | 4235*1520*2450 |
| SJSZ80 | 80/156 | 1-36.9 | 1800 | 55 | 36 | 360 | 1000 | 5000 | 4750*1550*2460 |
| SJSZ92 | 92/188 | 1-34.7 | 2500 | 110 | 88 | 1000 | 1000 | 5500 | 6000*1600*2500 |
PVC PIPE PRODUCTION LINE:
| 1. PVC raw material Auto Loader | 1 set |
| 2. High speed Mixer unit | 1 set |
| 3. Raw material Mixture Auto Loader | 1 set |
| 4. Main extruder | 1 set |
| 5. Mould/Die head | 1 set |
| 6. Vacuum calibration tank | 1 set |
| 7. Haul off machine | 1 set |
| 8. Cutting machine | 1 set |
| 9. Stacker | 1 set |
| 10. Words Printing machine | 1 set |
| 11. PVC pipe Crusher/Grinder | 1 set |
| 12. PVC Pulverizer/Milling machine | 1 set |
| 13. Color line co extruder | 1 set |
Remarks: with different pipe diameters, the machines configuration will be a little different as well.
