Home > Products > WPC/PVC profile production line > UPVC window profile plant
UPVC window profile plant
- 8 Set / Sets per Month
- shaghai
- T/T
Product Details
Condition: | New | Product Type: | PVC Profile | Place of Origin: | Jiangsu, China |
Brand Name: | Gerui | Model Number: | YF | Voltage: | 380V 50HZ; 220V 60HZ |
Power(W): | 37KW | Dimension(L*W*H): | 25*2*1.6M | Weight: | 15T |
Certification: | CE& ISO | Warranty: | 12 month | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
UPVC window profile plant1. produce upvc window profile
2. double screw extruder
3. turn-key project
UPVC window profile plant
1. produce upvc window profile
2. double screw extruder
3. turn-key project
The unit is optimized in design, referring to the newest foreign technology. The unit has the advantages of even plasticizing, small velocity of cutting, high output, long service-life and so on. The unit is composed of conical double-screw extruder, vacuum calibration table, haul off, cutter, foil machine, stackrack, etc. The main machine adopts thefrequency changer or the silicon-controlled rectifier directcrrent velocity modulation.The temperature control meter adopts the import or the joint calital product. The vacuum pump of the auxiliary parts and hauling motor both adopt high-quality products. The maintenance is simple and convenient. The unit is also able to direct extrude artificial wood foamed profile material. The result is better than that of the single-screw extruder. The plastics-steel door and window profile production line adopts conical double-screw extruder, which process PVC door and window profile materials, plastics-steel compound material, multiple-hole wire pipes, decoration profiles and so on.
Main applications:
This pvc profile extrusion line is composed of cone twin screw extruder, vacuum calibration tank, haul-off, cutter, stacker, and also coordinated with different profile break-section and mould to produce PVC door&window profile,indoor floor, decoration plate material, profile and multi-hole wire plastic products etc.
This extrusion line also can be used to produce wpc profile extrusion line WPC Machine can be used after recycling, and has been widely used in fields of floor, guard bar, tray, packing cases, partition board, window and door sheath, skirting line, etc.
Main technical parameter:
Type | YF-180 | YF-240 | YF-700 | YF-1000 |
Section bar width(mm) | 180 | 240 | 700 | 1000 |
Length of vacuum calibration tank(mm) | 2500 | 6000 | 6000 | 8000 |
Degree of vacuum(Map) | -0.08-0.09 | -0.08-0.09 | -0.08-0.09 | -0.08-0.09 |
Traction speed(m/min) | 0.5-0.4 | 0.5-0.4 | 0.3-3 | 0.2-1.0 |
Cutting saw diameter(mm) | 400 | 450 | 300 | 320 |
Total power(kw) | 42 | 98 | 180 | 250 |
Length of line(m) | 20 | 25 | 35 | 45 |
PVC window profiles:
Also used for producing the wpc window profiles
Contact Us
- Zhangjiagang Gerui Science & Technology Development Co., Ltd.
- Contact nameTony Chen
- Phone86-512-58529589,58522188
- AddressLefeng Road
