Zhanjiang Weida natural rubber pressing rubber creper
Working principle
This machine cosists of front and rear roll,adjusrtingmechanism,frame, transimission mechanism,reduer, motor and base, Using of front and rear roll ralative movement, so that to make rubber material ro be flat and pull out water and sundries of rubber. At the same time, because speed dissimilarity of front roll and rear roll would knead and shred rubber material into granulating shape, bar shape and honeycomb shape; production capacity of rubber creper machine uses according to production line.
Specification:
| Model | Wirking Dia(mm) | Working Length(mm) | Power(kw) | Capacity(t/h) | Dimension(L×W×H) |
| ZP200×600 | 200 | 600 | 7.5 | .8 | 1890×1330×1150 |
| ZP280×600 | 280 | 600 | 11 | 1 | 2300×1350×1170 |
| ZP300×600 | 300 | 600 | 15 | 1.2 | 2260×1590×1590 |
| ZP350×600 | 350 | 600 | 18.5 | 1.8 | 2015×1500×1210 |
| ZP350×700 | 350 | 700 | 22 | 2.5 | 3000×2050×1950 |
| ZP450×760 | 450 | 760 | 37 | 4 | 2700×1300×1600 |
| ZP560×760 | 560 | 760 | 55 | 8 | 3300×2200×1800 |
Function:
The machine is used for dewatering and pressing the rubber material into crepe sheet. We can use one creper in family workshop and several in production line as well.
About us:
We are a professional manfuacturer in China, rubber processing machines such as Rubber Prebreaker Machines, Rubber Shredder Machines, Twin Helix Breaking & Extruding Washing Machines, Rubber Cutter Machines, Rubber Cleaning Machines, and Belt Conveyer Machines , which mainly produce the natural rubber processing equipment to make the natural rubber into TSR, SMR, SCR, SIR, RSSrubber.
Please tell us ur requirement of the line if you need, so that we could design a suitable rubber production line to you.
FAQ:
we provide design and manufacturing services for different equipment and machines on request.
