15W New Portable Solar Energy System

Specifications

Portable Solar Power System
1.Solar Power:15W
2.Battery Capacy:12A
3.Certification:CE & FCC & ROHS
4.Solar power system

15W Portable Solar Power System

Characteristics: The system has high conversion of silicon solar cell, high euphotic rate and mechanical strength, good resistance to climate, preventing wind, hail. Which can effectively resist corrosion of moisture and salt fog,.conversion efficiency can be more than 15%, temperature range: - 25 to 80 degrees Celsius.

Applicance range: Electronic appliances such as mobilephone charging, notebook computers, lights, digital camera, video camera, TV, electric tools, music CD, DVD, electric power whose voltage is in 50Hz,220V, Design and manufacture as the small AC/DC power supply system, for farmers in remote areas, and posts, fieldwork, small tourist camping It is the necessary perfect product in the portable office, fieldwork,and cutoff.

Operation:

1 When product is produced,the power switch is  "OFF", turning "ON" when using.

2. Clicking " Light touch switch " ,LED digital diode display "6." ,showing off and on. meantime,AC220V DC12V output.

3 LED1 is "blue" when solar light charge for built-in battery.

4 LED2 is "green" when built-in battery working on a normal voltage, if turn red , "shows that built-in battery has a low working voltage.

5. LED3 is "red" when output works normally.

Technical parameters:

Solar panel: 18V /15w

Working voltage:18V

Working current:0.8A

Open-circuit voltage:21.6V

Short-circuit current:0.84A

Maximum system voltage:1000V

Short-circuit current temperature coefficient: 2.0 MA/°C

open-circuit voltage temperature coefficient: - 0.078 V/°C

Major system configuration:

1 Solar panels parameters :15W (monocrystalline or polycrystalline)

2 System controller :12V / 24 rotation 10A and intelligent control, LEDdisplay

3 Lead-acid battery:12V12AH full sealed waterproof and moistureproof

inverter, AC220V 150W

output voltage: DC 12V AC 220V voltage ( special for 110V)

 cabinet : 508*332*73mm

 weight: 6.8 KG

This system can support:

The above information is only for reference. Our R&D team can design the systerm according to the local natural resources and customers specific requirements.
