Home > Instruments & Meters > Test Instrument > Test Machine > IPC-8600ADH Professional ip Cctv Tester Ipc Cctv Tester Hot Sale Camera Tester
IPC-8600ADH Professional ip Cctv Tester Ipc Cctv Tester Hot Sale Camera Tester
US$ 350.68 - 350.68
MOQ: 2 Units
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Model Number:
IPC-8600ADH
Power:
Electronic
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
IPC-8600ADH ip Cctv System Tester HD-AHD/TVI/CVI Cam Test CCTV TesterUS$ 350.68 - 350.68MOQ: 2 Units -
IPC-9600SATC Tvi Camera Manufacturers Best Buy Security CameraUS$ 206.25 - 245MOQ: 2 Units
-
7"CCTV Camera Monitor Tester HVT-3600MOTS Multimeter W/ Optical Power+HD-SDI+TDRUS$ 300.21 - 300.21MOQ: 1 Unit
-
7" Touch Screen IPC Camera Display HD-AHD/TVI/CVI/SDI Camera PTZ Test Tester POEUS$ 360 - 360MOQ: 1 Unit
-
7"Monitor Security Camera CCTV Tester Ping IP Address/POE Check+4G Card HVT-3600US$ 149.31 - 149.31MOQ: 1 Unit
Place of Origin
Guangdong, China
Model Number
IPC-8600ADH
Power
Electronic
Usage
Other, AHD IPC Test Monitor
IPC-8600ADH 1920x1080 OSD ONVIF IP Analog HD-AHD/TVI/CVI Cam Test CCTV Tester
Model IPC-8600 ADH
Display 7 inch Capacitive touch screen , resolution 1024(RGB)x 600
WIFI Built in WIFI,speeds150M,display wireless camera image
IP camera type ONVIF,ACTi,Dahua IPC-HFW2100P,Hikvision,DS-2CD864-E13,Samsung SNZ-5200,Tiandy TD-NC9200S2,Kodak IPC120L,Honeywell HICC-2300T,Aipu-waton IP5000-BC-13MP/IRS06-13MP,fine-Tida IPC,FSJ BY-1080Q,WEISKY IPC camera etc. Customized welcome
Video input/output 1 channel BNC input & 1 channel BNC looped output, NTSC/PAL (Autoadapt)
Video Level Test: Video signals measured in IRE or mV
Video level meter PEAK video signal level, SYNC signal level, Color bar chroma level measurement
Zoom Image Support Analog camera and IP camera image zoom /move
Snapshot, Image Screen snapshot, record ,save ,view and record and play back
Video record and playback
HDMI output 1 channel HDMI output,support 1920*1080P
12V/2Apower output Output DC12V/2A power for camera
5V power output 5V 2A power output,as a Power bank
PoE power output 48V PoE power output,Max power 24W
Audio test 1 channel audio signal input, test whether sound normal, 1 channel audio signal, to connect headphone
PTZ control Support RS232/RS485 control, Baud 600-115200bps, Compatible with more than 30 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc
color bar generator Output one channel PAL/NTSC color bar video signal for testing monitor or video cable.(red, green ,blue, white and black color )
UTP Cable tester Test UTP cable connection status and display on the screen. Read the number on the screen
Data monitor Captures and analyzes the command data from controlling device,also can send hexadecimal
Network test IP address scan, link test, Ping test, Quickly search the connection IP camera and other device's IP address
Cable scan Search the cable by the audio signal
PoE test Measurement POE switch or PSE power supply voltage and cable connection status
POWER
External power supply DC 12V 2A
Battery Built-in 7.4V Lithium polymer battery ,6500mAh
Rechargeable After charging 7~8 hours, normal working time 16 hours
Parameter
Operation setting Capacitive touch screen, OSD menu, select your desired language: English, Chinese, Korean, Russian, Italian or Polish, etc
Auto off 1-30 (mins)
General
Working Temperature -10℃---+50℃
Working Humidity 30%-90%
Dimension/Weight 231mm x 172mm x 52mm / 1.26Kg
Display 7 inch Capacitive touch screen , resolution 1024(RGB)x 600
WIFI Built in WIFI,speeds150M,display wireless camera image
IP camera type ONVIF,ACTi,Dahua IPC-HFW2100P,Hikvision,DS-2CD864-E13,Samsung SNZ-5200,Tiandy TD-NC9200S2,Kodak IPC120L,Honeywell HICC-2300T,Aipu-waton IP5000-BC-13MP/IRS06-13MP,fine-Tida IPC,FSJ BY-1080Q,WEISKY IPC camera etc. Customized welcome
Video input/output 1 channel BNC input & 1 channel BNC looped output, NTSC/PAL (Autoadapt)
Video Level Test: Video signals measured in IRE or mV
Video level meter PEAK video signal level, SYNC signal level, Color bar chroma level measurement
Zoom Image Support Analog camera and IP camera image zoom /move
Snapshot, Image Screen snapshot, record ,save ,view and record and play back
Video record and playback
HDMI output 1 channel HDMI output,support 1920*1080P
12V/2Apower output Output DC12V/2A power for camera
5V power output 5V 2A power output,as a Power bank
PoE power output 48V PoE power output,Max power 24W
Audio test 1 channel audio signal input, test whether sound normal, 1 channel audio signal, to connect headphone
PTZ control Support RS232/RS485 control, Baud 600-115200bps, Compatible with more than 30 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc
color bar generator Output one channel PAL/NTSC color bar video signal for testing monitor or video cable.(red, green ,blue, white and black color )
UTP Cable tester Test UTP cable connection status and display on the screen. Read the number on the screen
Data monitor Captures and analyzes the command data from controlling device,also can send hexadecimal
Network test IP address scan, link test, Ping test, Quickly search the connection IP camera and other device's IP address
Cable scan Search the cable by the audio signal
PoE test Measurement POE switch or PSE power supply voltage and cable connection status
POWER
External power supply DC 12V 2A
Battery Built-in 7.4V Lithium polymer battery ,6500mAh
Rechargeable After charging 7~8 hours, normal working time 16 hours
Parameter
Operation setting Capacitive touch screen, OSD menu, select your desired language: English, Chinese, Korean, Russian, Italian or Polish, etc
Auto off 1-30 (mins)
General
Working Temperature -10℃---+50℃
Working Humidity 30%-90%
Dimension/Weight 231mm x 172mm x 52mm / 1.26Kg
7 inch touch screen AHD TVI CVI IP Analog tester
1. 7 inch touch screen,1024*600 resolution
2. Capacitive touch screen ,OSD menu,
3. Touch screen and key operation
4. Support 1080P camera
5. Support network PTZ controller (ONVIF)
6. Support mobile app of the IP camera
7. OSD menu rotates in 180 angle NEW4GB SD card including
8. HDMI signal output, supports up to 1080P.
9. 12V /2A power output NEW
10. PoE DC48V power output,Max power 24W NEW
11. Support 1080P HD video files and MKV/MP4 media files play
12. PTZ controller ,Photograph, Video record, Record playback
13. Display its genuine resolution of the IP camera images
14. Built in Wi-Fi: receives video from wireless cameras or IP cameras connected to the network NEW
15. Digital camera image test and video image zoom, record, screen snapshot, Photo viewer and playback
16. Support ONVIF, combine with more than 80 brand camera ,such as DAHUA,Haikang,KEDA,Samsung,HIKVISION and TIANDY camera.
17. Supports more than 30 protocols such as PELCO-P, PELCO-D, and SAMSUNG.
18. Video screen snapshot ,video recording ,files named and save, easy to find
19. Video level meter, Video PEAK lever, SYNC level, COLOR BURST measurement NEW
20. Enhanced Color bar generator: PAL/NTSC multi-system color bar video generator (Eight-system switchable, transmit/receive eight-system colorful images).
21. POE voltage measurement, PING test ,IP address scan, port flashing etc
22. 5V 2A power output,as the power bank NEW, (No USB data exchange, voltage only)
23. Audio in /out , support record and save the audi
24. LED lamp, calculators, music players and other application tools
25. Support customers self update software
26. Lithium Ion Polymer Battery, working time lasts 16 hours
27.HD TVI camera image display, zoom, video record and playback ,Coaxial PTZ control and call camera OSD menu
28. AHD camera image display, zoom, video record and playback, Coaxial PTZ control and call camera OSD menu
29. HD CVI camera image display, zoom, video record and playback ,Coaxial PTZ control and call camera OSD menu
1. 7 inch touch screen,1024*600 resolution
2. Capacitive touch screen ,OSD menu,
3. Touch screen and key operation
4. Support 1080P camera
5. Support network PTZ controller (ONVIF)
6. Support mobile app of the IP camera
7. OSD menu rotates in 180 angle NEW4GB SD card including
8. HDMI signal output, supports up to 1080P.
9. 12V /2A power output NEW
10. PoE DC48V power output,Max power 24W NEW
11. Support 1080P HD video files and MKV/MP4 media files play
12. PTZ controller ,Photograph, Video record, Record playback
13. Display its genuine resolution of the IP camera images
14. Built in Wi-Fi: receives video from wireless cameras or IP cameras connected to the network NEW
15. Digital camera image test and video image zoom, record, screen snapshot, Photo viewer and playback
16. Support ONVIF, combine with more than 80 brand camera ,such as DAHUA,Haikang,KEDA,Samsung,HIKVISION and TIANDY camera.
17. Supports more than 30 protocols such as PELCO-P, PELCO-D, and SAMSUNG.
18. Video screen snapshot ,video recording ,files named and save, easy to find
19. Video level meter, Video PEAK lever, SYNC level, COLOR BURST measurement NEW
20. Enhanced Color bar generator: PAL/NTSC multi-system color bar video generator (Eight-system switchable, transmit/receive eight-system colorful images).
21. POE voltage measurement, PING test ,IP address scan, port flashing etc
22. 5V 2A power output,as the power bank NEW, (No USB data exchange, voltage only)
23. Audio in /out , support record and save the audi
24. LED lamp, calculators, music players and other application tools
25. Support customers self update software
26. Lithium Ion Polymer Battery, working time lasts 16 hours
27.HD TVI camera image display, zoom, video record and playback ,Coaxial PTZ control and call camera OSD menu
28. AHD camera image display, zoom, video record and playback, Coaxial PTZ control and call camera OSD menu
29. HD CVI camera image display, zoom, video record and playback ,Coaxial PTZ control and call camera OSD menu
