asme sb 265 gr2 2mm 5mm titanium alloy plate/sheet

FOB Price

Negotiable / Kilogram

50 Kilograms(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Liaoning, China	Application	chemical industry, Metallurgy, marine engineering. military industry ,
Thickness	0.5mm to 80mm	Width	1000mm to 2500mm
Length	2000mm to 6000mm	Technique	Hot Rolled
Grade	GR1	Ti (Min)	99.5%
Brand Name	Jinyang	Model Number	GR1-GR9,TA0-TA10,

1) Long time use life;
2) Smooth surface and good quality;
3)Ti: 99.5%min
4) Standards:ASTM,and GB

Product info:

Product name: asme sb 265 gr2 2mm 5mm titanium alloy plate/sheet

Other names: asme sb 265 gr2 titanium plate

Product specification:

Production Name	Gr2 pure titanium sheet
Grade	Gr1Gr2Gr3
Size	0.3-60*400-30001000-4000mm
Standard	ASTM B265 ASTM F67 AMS 4911
Supply status	M
Application	chemical industry, Metallurgy, marine engineering. military industry ,medical industry, Electroplating industry, ,precision instrument,sport ,car
Feature	High corrosion resistance ,low density, good thermal stability
Packing	Wooden case as outside,plastic bag as inside,or standard export packaging
Payment terms	L/C T/T
Delivery time	10-30days according to the quantity and process of the product
Quality And test	Strict test is indispensible,because we must insure our clients get the best product

Product properties:

Grade	Supply State	Titanium sheet Thickness(mm)	Tensile strength Rm/MPa(>=)	Provision of non-proportional Extension strength Rp_0.2/MPa	Break Elongation ^aA/%(>=)
Gr1	M	0.3-25.0	240	140-310	30
Gr2	M	0.3-25.0	400	275-450	25
Gr3	M	0.3-25.0	500	380-550	20
Gr4	M	0.3-25.0	580	485-655	20
Gr5	M	0.8-2.0 2.0-5.0 5.0-10.0 10.0-25.0	895	>830	12 10 10 8
Gr6	M	0.8-1.5 >1.6-2.0 >2.0-5.0 >5.0-10.	735-930	>685	20 15 12 12
Gr7	M	0.8-10	400	275-450	20
Gr9	M	0.5-2.0 2.0-4.0 4.0-10.0	590-735	---	25 20 15
TC4ELI (Gr23)	M	0.8-25.0	860	>795	10

Products photos:

The certificates we got
