High Temperature Type e Type k Type j Type t Type n Thermocouple Wire

Name: High Temperature Type e Type k Type j Type t Type n Thermocouple Wire
Brand: Jinyang
SKU: 129894845
Availability: InStock

Negotiable MOQ: 50 Kilograms (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Liaoning, China

Brand Name:

Jinyang

Model Number:

K E J T N

Shenyang Tianzhong Alloy Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian port or other Chinese ports

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Liaoning, China

Brand Name Jinyang

Model Number K E J T N

Type Other

Application Other

Conductor Material Other

Conductor Type Other

Insulation Material Other

Specifications

1) With high thermoelectromotive force
2) High stability,superior processability
3) Used for testing temperature

Product info

Product name: high temperature type e type k type j type t type n thermocouple wire

Other names: high temperature thermocouple wire

Specification

Product code	Indexing no.	Grade	Allowable tolerance	Temperature range		Executive standard
				Long term	Short term
Nickel chrome-nisiloy	K	I	±1.5°Cor±0.4%t	-40~1200	-40~1300	GB/T2614-2010
		II	±2.5°Cor±0.75%t
Nickel chrome-Copper nickel(Constantan)	E	I	±1.5°Cor±0.4%t	-40~750	-40~900	GB/T4993-2010
		II	±2.5°Cor±0.75%t
Iron-Copper nickel (Constantan)	J	I	±1.5°Cor±0.4%t	-40~600	-40~750	GB/T4994-1998
		II	±2.5°Cor±0.75%t
Copper-Copper nickel (Constantan)	T	I	±0.5°Cor±0.4%t	-200~300	-200~350	GB/T2903-1998
		II	±1.5°Cor±0.75%t
		III	±1°Cor±1.5%t
NiCrSi-NiCrMg	N	I	±1.5°Cor±0.75%t	-40~1200	-40~1300	GB/T17615-1998
		II	±2.5°Cor±0.75%t
