Vacuum Forming Machine1) High capacity vacuum
2) Easy move and operate
3) Loog service time
4) CE
Vacuum Forming Machine is necessary equpiment in plastic double pipe production line.
XK Vacuum forming machine
Features:
1.This machine has a high power pick-up vacuum pump and large bed size. Custom made heating elements have a life rated at 8-10 thousand hours and can comfortably run 24 hours a day.
2.Working platform is made of steel and has been heat processed preventing distortion and extending the life of the machine.
3.The temperature control is regulated and thermostatically controlled. The entire lid is covered in heat reflective material assisting in heating thus making the unit energy efficient and saving on power.
4.This machine is fully automatic. Simply place your mold inside the cabinet, close the lid and press the button..
5.The machine automatically heats and softens the acrylic to your specified temperature, then engages the pump at the correct temperature and creates the mold all in 1 process.
Technical data:
Model |
XK-1400 |
XK-2700 |
XK-3020 |
Xk-3700 |
BX4020 |
Working area(mm) |
1320x1320 |
2620x1320 |
3010x2100 |
3620x2100 |
4000*2000 |
Total power(kw) |
8 |
16 |
24 |
32 |
36 |
Max sheet thickness(mm) |
20 |
20 |
20 |
20 |
20 |
Max suction forming depth(mm) |
80 |
80 |
80 |
80 |
80 |
Softening oven temperature(°C) |
0-400 ^ |
0-400 ^ |
0-400^ |
0-400^ |
0-400^ |
Voltage(V) |
AC380/50-60HZ |
AC380/50-60HZ |
AC380/50-60HZ |
AC380/50-60HZ |
AC380/50-60HZ |
Overall size (mm) L*W*H |
1500*1500*1250 |
2750*1500*1250 |
3190*2200*1250 |
3820*2200*1250 |
4200*2150*1250 |
Weight (kgs) |
350 |
550 |
1200 |
1800 |
2000 |
Applicable material |
acrylic, ABS,PC, PS boards, PVC plates, etc. plate-forming industry. |
||||
PS: if you have any requirements about our machine , please feel free to contact with me . | |||||
Simple Working Process :
1. Fixed the mold
2. Move the material to soften oven box
3. Start heating button
4. After soften well the vacuum pump automatic working
5. Separate the mold and material
