Plastic Extruders Machinery--xinke
Negotiable
/ Piece
1 Piece(Min.Order)
- 13 Set / Sets per Month
- FOB shanghai and zhangjiagang port
- T/T
You May Like
Product Details
| Condition: | New | Application: | Pipe | Plastic Processed: | PVC |
| Screw Design: | Single-screw | Automatic Grade: | automatic | Place of Origin: | Jiangsu, China |
| Brand Name: | xinke | Model Number: | XK | Voltage: | 380v 50hz |
| Weight: | 500kg | Certification: | ce iso | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Plastic Extruders Machinery--xinke.Screw diameter:45/90mm-92-188mm
2.Pipe range:16-630mm
3.Capacity:60-750kg/h
Plastic Extruders Machinery
We are a professional manufacturer for all kinds of plastic extruders, such single screw extruders, twin screw extruders. With some necessary auxiliary machines, the production line can produce plastic pipes, plastic sheets, plastic profiles. With some other necessary auxiliary machines, the production line can be used for pelletizing. Co-rotating twin-screw extruder can be used for compounding of all kinds of plastics.
Main Features:
1. Reduction torque distribution gear casing of performance
2. High precision,wide range speed adjusting,forced quantitative feeder
3. Reliable and effective vacuum exhaust unit
4. Screw core circulating oil heating device,convenient for temperature control
5. High efficiency,low noise air cooling system
6. Perfect and precise automatic temperature control system
7. Precise and steble speed control system
Main technical parometer:
Model | SJZ45/90 | SJZ51/105 | SJZ55/110 | SJZ55/115 | SJZ65/132 | SJZ80/156 | SJZ92/188 |
Power of drive motor | 15 | 18.5 | 22 | 22 | 37 | 55 | 110 |
Screw diameter | 45/90 | 51/105 | 55/110 | 55/115 | 65/132 | 80/156 | 92/188 |
No.of screw | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
Nm Torsional moment of screw | 3148 | 6000 | 7000 | 7000 | 10000 | 14000 | 32000 |
Capacity PVC,powder | 60 | 100 | 120 | 180 | 250 | 400 | 750 |
Dimensions(mm) | 3360×1290 ×2127 | 3360×1290 ×2127 | 3620×1050 ×2157 | 3620×1050 ×2157 | 3715×1520 ×2450 | 4750×1550 ×2460 | 6725×1550 ×2814 |
