Yugong drum wood chipper,wood branch crusher machine
- 25 Set / Sets per Month
- China port
- T/T L/C D/P D/A
You May Like
-
Yugong big capacity drum wood chipper made in China
-
CE wood branch chipper,wood chipper made in china
-
Large capacity drum wood chipper for wood pellet making line
-
Yugong Brand reliable quality wood chips crusher , 2-15 t/h drum wood chipper
-
Factory supply heavy duty wood chipper for sale
-
factory directly supply disc wood chipper with good price
Product Details
| Condition | New | Place of Origin | Henan, China | |
| Brand Name | Yugong | Model Number | BX series | |
| Voltage | 380V or customized | Power(W) | 55-110kw | |
| Dimension(L*W*H) | 1800*1900*1210mm | Weight | 4-7t | |
| Certification | CE | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Yugong drum wood chipper,wood branch crusher machine
Product Description of wood branch crusher machine
Yugong wood branch crusher machine is mainly used for cutting branches, small trees, paper plates, planks with diameter or thickness below 120mm. The cut wood chips is used as pellets making raw material. The cutting part is a rotating drum with a number of cutting knives which can process wood into wood chips.
Technical Parameters of wood branch crusher machine
Model
Item | BX215 | BX216-3 | BX218-6 |
Feeding Conveyor (length, m) | 6 | 6 | 8 |
Discharging Conveyor (length, m) | 13.6 | 13.6 | 13.6 |
Inlet Dimension (mm) | 160*400 | 230*500 | 300*680 |
Blades Qty (pcs) | 2 | 3 | 6 |
Knife Roll Diameter (mm) | 500 | 600 | 800 |
Knife Roll Speed (rpm) | 592 | 590 | 650 |
Max. Chipping Diameter (mm) | 160 | 230 | 300 |
Size of Finish Chips (length*width*thickness, mm) | 20/25*20/25*5 | 20/25*20/25*5 | 20/25*20/25*5 |
Capacity (based on upper final size, t/h) | 2 | 3 | 8 |
Main Motor Power (kw) | 45 | 55 | 110 max |
Feeding Motor Power (kw) | 2.2 - 3 | 3 - 4 | 4 - 5 |
Discharging Motor Power (kw) | 3 | 3 | 3 |
Oil Pump Motor Power (kw) | 1.5*1 | 1.5*1 | 1.5*1 |
Machine Weight (kg) | 2990 | 4070 | 7000 |
External Dimension (mm) | 1470*1550*970 | 1800*1900*1210 | 2200*2150*1500 |
The wood branch crusher has been exported to many countries,and to be welcomed.
vide suitable wood brand crusher machine accoring to your detailed requirements.
technical service
available to service machinery overseas
vide spare parts to ensure continuous production
If you have any needs for wood branch crusher machine,just feel free to contact us.
