Double Stage Hammer Crusher With Unique Design
About Us --double stage hammer crusher
Q:Are you a factory or trading company?
A:We are the professional manufacturing factory and we have exported our products to many foreign countries.
Q:Where is your factory located? How can I visit there?
A:Our factory is located in Gongyi City( Henan Province, China, )near Zhengzhou City.You can fly to Zhengzhou Xinzheng International Airport and we can go to airport to pick you up directly.All our clients from home or abroad, are warmly welcome to visit our factory and inspect our products!
Application of double stage hammer crusher
Double stage crusher can be widely used in crushing coal gangue, shale, clay, slag, shale limestone, construction wastes, tailing ore and other materials. It is easy to crush high moisture materials.
We could be the good one and the reliable quality, reasonable structure and we want to be the reasonable structure.
Technical parameters of double stage hammer crusher:
Model |
Max crushing diameter |
Final size |
Capacity (t/h) |
Raw material Moisture content |
Main Motor Power(kw) |
External Dimension (mm) |
SCF600×400 |
≤100 |
≤3mm |
15-25 |
<20% |
18.5+18.5(15) |
2450×1020×1700 |
SCF600×600 |
≤110 |
20-30 |
22+22(18.5) |
2450×1280×1650 |
||
SCF800×600 |
≤120 |
35-55 |
45+45(37) |
3760×1314×2100 |
||
SCF800×700 |
≤120 |
45-60 |
45+55(45) |
3485×1400×2254 |
||
SCF800×800 |
≤120 |
50-60 |
45+55 |
3760×1840×2100 |
||
SCF900×800 |
≤120 |
50-70 |
55+75 |
3950×1750×2280 |
||
SCF1000×800 |
≤180 |
60-90 |
75+55 |
4100×1840×2450 |
||
SCF1100×1000 |
≤180 |
80-100 |
90+110 |
4086×2030×2337 |
||
SCF1400×1200 |
≤200 |
100-120 |
132+160 |
5800×2658×3210 |
Features of double stage hammer crusher:
1.High fineness of discharging size: favorable shape with aggregate, the powdery material is no more than 20%;
2.The lubrication system is safe and reliable, Easy to replace parts, Low workload of maintenance;
3.High fineness of discharging size: favorable shape with aggregate, the powdery material is no more than 20%;
4.Primary crushing and secondary crushing in one step, simplify the process;
5.High finished product rate, granularity finished products account of 80%, meet the requirement;
6.Rotating part with thermal refined structure by CNC, make the rotating part higher toughness.
The main parts of double stage hammer crusher:
Guarantee and After-sale Service:
• one year guarantee
• 24 hours techinical support by e-mail
• Calling or door-to-door service
Double Stage Hammer Crusher With Unique Design made by Gongyi Yugong Factory.
Welcome inquire us ~
