Common Rail Injector Test Bench TST-708

Common Rail Injector Test Bench TST-708 thumbnail-1
Common Rail Injector Test Bench TST-708 photo-1
US$ 1,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
APS
Model Number:
TST-708
Power:
Electronic
Contact Supplier Request Quote Chat Now
Shaanxi APS Machinery Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name APS
Model Number TST-708
Power Electronic
Usage Auto Testing Machine

Common Rail Injector Test Bench – TST-708

Common Rail Injector Test Bench TST-708

TST-708



Functions:





1.Application: Bosch,Delphi,Denso,Siemens common rail injector and pump.

2.Pump test: measure feeding and return volume,pump chamber pressure,feeding pressure,check sealing performance, and functions of ZME valve.

3.Injector test: measure the injected fuel quantity & return volume under full-loaded, idling, pre-injection and Emission status.

4. Check the sealing performance of the injector.

5. Check the solenoid valve.

6. Clean the injector and pump before testing.

7. Clean the ZME separately.

8.User can add and edit the data by themselves.











 CHARACTERISTIC:


1. Full-automatic operation procedure, save the time to set up the data.

2. Flow sensor: test precision 0.5%.

3.Rail pressure is controlled accurately by ZME valve and DRV(optional)

4. Test oil temperature controlling kit enables the temperature to be constant at 40±2°C,through the cooling and heating systems



5. Original Bosch common rail pump is equipped.

6. Industrial computer with windows system.

7. Self-protection under following status:overheat, oil-mist, overpressure, low oil level,





Main technical parameters:


1. Power: 11kw, 15kw (optional)

2. Oil pump rotation speed: 0-4000rpm

3. Test rang of rail pressure: 0-2000bar

4. Test precision of rail pressure: ±0.5Mpa

5. Test precision of flow sensor: 0.5%

6. Measuring rang of flow sensor: 0.008-2L/Min

7. Temperature of test oil:40±2℃

8. Filter precision of test oil: less than 5μ

9. Capacity of tank: 40L

10. Dimension: 1750X700X1500MM

11. Aggregate weight: 850KG
