Downhole API 5CT Oil Casing Pipe for Steel Grade J55, N80/Petroleum Casing and Tubing for Oil Drilling Equipment in Oil and Gas
US$ 1 - 200
MOQ: 1 Meter
Key Specifications
Get Latest Price
Standard:
Grade:
Thickness:
5.21, 16.13
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Downhole API Drill Collar/Integral Spiral Drill Collar/Oil and Gas Non Magnetic Drill Rod Collar Oil Drilling EquipmentUS$ 1,000 - 10,000MOQ: 1 Piece -
API Drill Collar/Integral Spiral Drill Collar/Oil and Gas Non Magnetic Drill Rod Collar Oil Drilling EquipmentUS$ 1,000 - 10,000MOQ: 1 Piece
-
API 5CT Oil Pipe Casing Pipe for Steel Grade J55, N80/Petroleum Casing and Tubing for Oil Drilling Equipment in Oil and GasUS$ 1 - 200MOQ: 1 Piece
-
Drill Pipe in Oil and Gas API 5DP Steel Drill Pipe Grade E75, G105, S135 Drill Rod, Oil Drilling EquipmentUS$ 1 - 3,000MOQ: 1 Ton
-
API 5CT Oil Pipes Tubing Pipe in Drilling Equipment/OCTG Grade J55 N80 Steel Tubing Drill Rod in Oil and GasUS$ 1 - 100MOQ: 10 Pieces
Thickness
5.21, 16.13
Section Shape
Round
Outer Diameter
4.05 - 20 mm
Secondary Or Not
Non-secondary
Application
Oil Pipe
Technique
Hot Rolled
Certification
API
Surface Treatment
Other, Black painting, Galvanized, Oiled, Anti-corrosion painting etc
Special Pipe
API Pipe
Alloy Or Not
Non-alloy
Downhole API 5CT Oil Casing Pipe for Steel Grade J55, N80/Petroleum Casing and tubing for oil drilling equipment in oil and gas
Product Description
* Details:
Casing is large diameter pipe that is assembled and inserted into a recently drilled section of a borehole and typically held into place with cement. And we provide various Seamless Casing from 4-1/2’’-20’’ in grade H40, J55,K55,N80,L80,C95,P110 etc. The Casing length range is R1,R2,R3,with threads of BTC,LTC,STC. According to the strength of steel casing can be divided into different steel grade, deep well, using different steel grade. In corrosive environment also requires the casing itself has corrosion resistance. In the complicated geologic condition place also asked the casing having a anti-collapse performance.
* Specifications: Oil Casing Pipe
| OD: | 4-1/2“ to 20“/ 114.3mm to 508mm |
| Wall Thickness: | 5.21 - 16.13 mm |
| Thread: | STC.BTC.LTC |
| Length: | R1(4.88-7.62M). R2(7.62-10.36M). R3(10.36-14.63Meters) |
| Standard: | API 5CT |
Grade: |
J55, K55, M65, N80,N80-1, N80-Q, L80-1, L80-9Cr, L80-13Cr, C90, C95, T95, P110, Q125 |
Technical parameter
| Outside Diameter | Wall Thickness | Grade | Thread | ||
| Inch | mm | kg/m | Ib/ft | ||
| 4 1/2'' | 114.3 | 14.14-22.47 | 9.50-15.10 | J55/K55/N80/L80/P110 | STC/LTC/BTC |
| 5'' | 127 | 17.11-35.86 | 11.50-24.10 | J55/K55/N80/L80/P111 | STC/LTC/BTC |
| 5 1/2'' | 139.7 | 20.83-64.14 | 14.00-43.10 | J55/K55/N80/L80/P112 | STC/LTC/BTC |
| 6 5/8'' | 168.28 | 29.76-47.62 | 20.00-32.00 | J55/K55/N80/L80/P113 | STC/LTC/BTC |
| 7'' | 177.8 | 25.30-84.98 | 17.00-57.10 | J55/K55/N80/L80/P114 | STC/LTC/BTC |
| 7 5/8'' | 193.68 | 35.72-82.30 | 24.00-55.30 | J55/K55/N80/L80/P115 | STC/LTC/BTC |
| 8 5/8'' | 219.08 | 35.72-72.92 | 24.00-49.00 | J55/K55/N80/L80/P116 | STC/LTC/BTC |
| 9 5/8'' | 244.48 | 48.07-112.51 | 32.30-75.60 | J55/K55/N80/L80/P117 | STC/LTC/BTC |
| 10 3/4'' | 273.05 | 48.74-126.94 | 32.75-85.30 | J55/K55/N80/L80/P118 | STC/LTC/BTC |
| 11 3/4'' | 298.45 | 62.50-105.66 | 42.00-71.00 | J55/K55/N80/L80/P119 | STC/LTC/BTC |
| 13 3/8'' | 339.73 | 71.43-107.15 | 48.00-72.00 | J55/K55/N80/L80/P120 | STC/LTC/BTC |
| 16'' | 406.4 | 96.73-162.21 | 65.00-109.00 | J55/K55/N80/L80/P121 | STC/LTC/BTC |
| 18 5/8'' | 473.08 | 130.22 | 87.5 | J55/K55/N80/L80/P122 | STC/LTC/BTC |
| 20'' | 508 | 139.89-197.93 | 94.00-133.00 | J55/K55/N80/L80/P123 | STC/LTC/BTC |
Visual Flow Chart
Test & Production
Note
