Home > Metallurgy, Mineral & Energy > Steel & Products > Steel Pipe & Tube > API 5CT Seamless Casing Pipe in Oilfield, Steel Grade J55,N80,P110,PH-6/Petroleum Casing and Tubing in Oil and Gas Downhole
API 5CT Seamless Casing Pipe in Oilfield, Steel Grade J55,N80,P110,PH-6/Petroleum Casing and Tubing in Oil and Gas Downhole
US$ 1 - 200
MOQ: 1 Meter
Key Specifications
Get Latest Price
Standard:
Grade:
Thickness:
5.21, 16.13
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
API Integral Lifting Sub/Drill Collar Lift Sub in Oil and Gas for Oil Drilling EquipmentUS$ 20 - 500MOQ: 1 Piece -
API Drill Collar/Integral Spiral Drill Collar in Drill Rod/Non-magnetic Drill Collar in Oil and GasUS$ 1,000 - 10,000MOQ: 1 Piece
-
API 5DP Drill Pipe/Oil Pipe Grade E75, X95, G105, S135 for Oil Drilling Tools in Oil and GasUS$ 70 - 500MOQ: 1 Piece
-
Downhole Tools API 5CT Oil Casing Pipe of Steel Grade J55, N80, L80, PH-6 /Petroleum Casing and Tubing in Oil and GasUS$ 1 - 200MOQ: 1 Meter
-
API Oilfield Casing Centralizer for Oil Pipe/Bow Spring Centralizer in Oil and GasUS$ 1 - 50MOQ: 1 Piece
Thickness
5.21, 16.13
Section Shape
Round
Outer Diameter
4.05 - 20 mm
Secondary Or Not
Non-secondary
Application
Oil Pipe
Technique
Hot Rolled
Certification
API
Surface Treatment
Other, Black painting, Galvanized, Oiled, Anti-corrosion painting etc
Special Pipe
API Pipe
Alloy Or Not
Non-alloy
API 5CT Seamless Casing Pipe in oilfield, Steel Grade J55,N80,P110,PH-6/Petroleum Casing and tubing in oil and gas downhole
Product Description
* Details:
Casing is large diameter pipe that is assembled and inserted into a recently drilled section of a borehole and typically held into place with cement. And we provide various Seamless Casing from 4-1/2’’-20’’ in grade H40, J55,K55,N80,L80,C95,P110 etc. The Casing length range is R1,R2,R3,with threads of BTC,LTC,STC. According to the strength of steel casing can be divided into different steel grade, deep well, using different steel grade. In corrosive environment also requires the casing itself has corrosion resistance. In the complicated geologic condition place also asked the casing having a anti-collapse performance.
* Specifications: Oil Casing Pipe
| OD: | 4-1/2“ to 20“/ 114.3mm to 508mm |
| Wall Thickness: | 5.21 - 16.13 mm |
| Thread: | STC.BTC.LTC |
| Length: | R1(4.88-7.62M). R2(7.62-10.36M). R3(10.36-14.63Meters) |
| Standard: | API 5CT |
Grade: |
J55, K55, M65, N80,N80-1, N80-Q, L80-1, L80-9Cr, L80-13Cr, C90, C95, T95, P110, Q125 |
Technical parameter
| Outside Diameter | Wall Thickness | Grade | Thread | ||
| Inch | mm | kg/m | Ib/ft | ||
| 4 1/2'' | 114.3 | 14.14-22.47 | 9.50-15.10 | J55/K55/N80/L80/P110 | STC/LTC/BTC |
| 5'' | 127 | 17.11-35.86 | 11.50-24.10 | J55/K55/N80/L80/P111 | STC/LTC/BTC |
| 5 1/2'' | 139.7 | 20.83-64.14 | 14.00-43.10 | J55/K55/N80/L80/P112 | STC/LTC/BTC |
| 6 5/8'' | 168.28 | 29.76-47.62 | 20.00-32.00 | J55/K55/N80/L80/P113 | STC/LTC/BTC |
| 7'' | 177.8 | 25.30-84.98 | 17.00-57.10 | J55/K55/N80/L80/P114 | STC/LTC/BTC |
| 7 5/8'' | 193.68 | 35.72-82.30 | 24.00-55.30 | J55/K55/N80/L80/P115 | STC/LTC/BTC |
| 8 5/8'' | 219.08 | 35.72-72.92 | 24.00-49.00 | J55/K55/N80/L80/P116 | STC/LTC/BTC |
| 9 5/8'' | 244.48 | 48.07-112.51 | 32.30-75.60 | J55/K55/N80/L80/P117 | STC/LTC/BTC |
| 10 3/4'' | 273.05 | 48.74-126.94 | 32.75-85.30 | J55/K55/N80/L80/P118 | STC/LTC/BTC |
| 11 3/4'' | 298.45 | 62.50-105.66 | 42.00-71.00 | J55/K55/N80/L80/P119 | STC/LTC/BTC |
| 13 3/8'' | 339.73 | 71.43-107.15 | 48.00-72.00 | J55/K55/N80/L80/P120 | STC/LTC/BTC |
| 16'' | 406.4 | 96.73-162.21 | 65.00-109.00 | J55/K55/N80/L80/P121 | STC/LTC/BTC |
| 18 5/8'' | 473.08 | 130.22 | 87.5 | J55/K55/N80/L80/P122 | STC/LTC/BTC |
| 20'' | 508 | 139.89-197.93 | 94.00-133.00 | J55/K55/N80/L80/P123 | STC/LTC/BTC |
Visual Flow Chart
Test & Production
Note
