Specifications
Fish Smoker:1. 304 stainless steel
2. with plates and cart
3. capacity 50-1000kg/batch
Fish Processing Plant for Smoking 50--1000kg/batch
Description:
1. It has functions of steaming, frying, boiling and smoking. It is easy to operate.
2. Excellent insulation and sealing performance. It has low energy consumption and high efficiency.
3. It consist of the stove body, heating system, circulated air system, electronic control and so on.
4. There is alarm when the processing is finished or breakdown happens.
5. The electric control system: it automatically control, monitor and show every step. It can save 99 programs. The human-computer interface shows you every process and data, including the adjustable relative humidity, the temperature of inner stove, the temperature of sausage core, process time, and procedure name, procedure index. Smoking and recycle system makes the smoke spread so equably that the sausage have uniform color.
Technical Data:
Model |
FMF100 |
FMF250 |
FMF500 |
FMF1000 |
Productivity |
≤100 kg/stove |
250 kg/stove |
500kg/stove |
1000kg/stove |
Power |
6kw |
7.5kw |
13.5kw |
27kw |
High pressure steam pressure |
0.3~0.6 Mpa |
0.3~0.6 Mpa |
0.3~0.6 Mpa |
0.3~0.6 Mpa |
Low pressure steam pressure |
0.1~0.2 Mpa |
0.1~0.2 Mpa |
0.1~0.2 Mpa |
0.1~0.2 Mpa |
Smoke introduction ignition |
≤15 min |
≤15 min |
≤15 min |
≤15 min |
Inner stove temperature |
95°C |
95°C |
95°C |
95°C |
Hydraulic pressure |
0.2Mpa |
0.2Mpa |
0.2Mpa |
0.2Mpa |
Standard trailer (mm) |
1000×1030×800 |
1000×1030×1980 |
1000×1030×1980 |
1000×1030×1980 |
Main engine size (mm) |
1290×1510×1700 |
1290×1510×2600 |
2420×1510×2600 |
4765×1510×2600 |
Installation dimensions (mm) |
4000×2200×3400 |
4000×2200×3400 |
6000×2200×3400 |
8000×2200×3400 |
Weight |
900kg |
1400kg |
1800 |
2600 |
Order process:
offer -- place order -- make contract – advance payment --production -- book shipping space-- delivery -- B/L copy -- down payment -- send the buyer the original B/L -- ship reach the destination-- The buyer picks up the goods with original B/L
Delivery time: within 15 working days after got your payment
Payment Term:T/T or Western Union, L/C
Validity Period: 3 weeks
Package: wooden case
If you are interested in any of our products, please feel free to contact us.
