SDD type Manual tongs/API standard handing tools for oil drilling top quality
* SDD Manual Tong handle size from :4-17"/135kN.m Rated Capacity:135KN·m. There are 1-5# lug jaws, hinged jaws 4" to 17" ,Maximum Rated Capacity 100,000ftlbs manufactured to API standard.
* Specification
1. Model: Type SDD
2. Standard: API Spec 7K Specification for drilling and well servicing equipment.
3. Manual tongs are necessary tools applied to make up and break out pipes.
4. Changing lug jaws and latch steps can adjust different handling sizes of the tongs.
No. of Latch Lug Jaw |
No. of Hinge Pin Hole |
Latch Step |
Size range |
Rated Torque (kN.m) |
|
in |
mm |
||||
1# |
Ⅰ |
1 |
4~5-1/2 |
101.6~139.7 |
135 |
2 |
5-1/2~5-3/4 |
139.7~146 |
|||
Ⅱ |
1 |
5-1/2~6-5/8 |
139.7~168.3 |
||
2 |
6-1/2~7-1/4 |
165.1~184.2 |
|||
Ⅲ |
1 |
6-5/8~7-5/8 |
168.3~193.7 |
||
2 |
7-3/4~8-1/2 |
196.9~215.9 |
|||
2# |
Ⅰ |
1 |
8-1/2~9 |
215.9~228.6 |
|
2 |
9-1/2~10-3/4 |
241.3~273 |
|||
Ⅱ |
2 |
10-3/4~12 |
273~304.8 |
||
3# |
Ⅰ |
1 |
12~12-3/4 |
304.8~323.8 |
100 |
Ⅱ |
1 |
13-3/8~14 |
339.7~355.6 |
||
2 |
15 |
381 |
|||
4# |
Ⅱ |
1 |
15-3/4 |
400 |
135 |
5# |
Ⅱ |
1 |
16 |
406.4 |
80 |
2 |
17 |
431.8 |
|||
