Product Details
| Brand Name: | APS | Model Number: | API Mechanical Hydraulic Drilling Jar | Type: | Other, Drilling Jar |
| Machine Type: | Drilling Tool | Certification: | API | Material: | Carbon Steel |
| Processing Type: | Forging | Use: | Well Drilling |
Product Description
API spec Model JZ/JSZ Oil Well Drilling Jar,Model JYQ for Mechanical/Hydraulic Drilling Jar, QY Hydraulic in oil and gas
Type for drilling jar:
Model ZSXJ Drilling Jar, Model JZ Mechanical Drilling Jar, Model JSZ Mechanical Drilling Jar, Model JYQ Mechanical-Hydraulic Drilling Jar, Model QY Full Hydraulic Drilling Jar, Model QYⅡFull Hydraulic Drilling Jar.
We can design specification products as per customer requirements.
Model | OD mm (in) | ID mm (in) | Connections API | Max. Tensile load kN (Ibf) | Max. Working torque kN.M (Ibf·ft) | Pumping area cm2 | Up jar stroke mm | Down jar stroke mm | Overall length (in locked position) mm |
JZ95Ⅱ | 95 (3 3/4) | 25 (1) | 2 7/8REG | 600 (135000) | 4 (3000) | 34.6 | 149 | 166 | 5624 |
JZ108Ⅱ | 108 (4 1/4) | 36 (1 27/64) | NC31 | 800 (180000) | 10 (7400) | 40 | 203 | 203 | 6404 |
JZ121Ⅱ | 121 (4 3/4) | 45 (1 3/4) | NC38 | 1100 (247000) | 15 (11000) | 48 | 198 | 206 | 6354 |
JZ127 | 127 (5) | 45 (1 3/4) | NC38 | 1200 (270000) | 15 (11000) | 48 | 198 | 206 | 6354 |
JZ140 | 140 (5 1/2) | 50 (2) | NC38 | 1350 (303000) | 20 (15000) | 59 | 150 | 165 | 6300 |
JZ15IV | 159 (6 1/4) | 57 (2 1/4) | NC46 | 1600 (360000) | 25 (18500) | 78 | 149 | 166 | 6517 |
JZ165Ⅱ | 165 (6 1/2) | 57 (2 1/4) | NC50 | 2000 (450000) | 25 (18500) | 78 | 149 | 166 | 6517 |
JZ178Ⅱ | 178 (7) | 71.4 (2 13/16) | NC50 | 2400 (540000) | 30 (22000) | 93 | 160 | 182 | 7266 |
JZ203Ⅱ | 203 (8) | 71.4 (2 13/16) | 6 5/8REG | 2800 (630000) | 35 (25800) | 136 | 160 | 182 | 7234 |
JZ229Ⅱ | 229 (9) | 76 (3) | 7 5/8REG | 3000 (670000) | 35 (25800) | 181 | 203 | 203 | 7754 |
TYPE | O.D. mm | I.D. mm | Connection API | Upward jarring stroke mm | Downward jarring stroke mm | Max. Upward Jarring force kN | Max. Downward jarring force kN | Overall length mm |
JSZ124 | 124 | 51.4 | NC38 | 227 | 152 | 440 | 20 | 4150 |
JSZ159 | 159 | 63.5 | NC50 | 227 | 152 | 630 | 360 | 4 223 |
JSZ168 | 168 | 57.2 | NC46 | 229 | 152 | 850 | 75 | 4150 |
JSZ178 | 178 | 57.2 | NC50 | 229 | 152 | 1050 | 100 | 4150 |
JSZ203 | 203 | 71 | 65/8REG | 232 | 226 | 820 | 460 | 4 904 |
