Help CenterMonochrome Metallographic Analysis Invert Microscope Camera
Related Products
-
High Quality Mini Ccd Camera Industrial Camera Usb3.0US$ 1 - 235MOQ: 1 Piece -
New Design Mini Global Shutter Color Ccd Endoscope CameraUS$ 238 - 248MOQ: 1 Piece
-
2016 New Brand CCD Monochrome Camera LWIR CameraUS$ 1 - 235MOQ: 1 Piece
-
New Design 26fps Progressive Scan Mini Industrial CameraUS$ 238 - 248MOQ: 1 Piece
-
China Made 0.4V/lux-sec 550nm Sensibility USB3.0 Stereo Microscope CameraUS$ 238 - 248MOQ: 1 Piece
Sensor Model | 1/3" CCD Mono |
Sensor Dimension | 4.65μmx4.65μm |
Frame rate | 26fps |
Scan Method | Progressive scan |
Sensibility | 0.4V/lux-sec(550nm) |
Resolution | 30fps@1024x768 |
Shutter | Global shutter |
Dynamic Rate | 61dB |
SNR | 44dB |
Spectral Response | 400nm~700nm |
Data Interface | USB3.0,5Gbps,3M Cable |
Power | DC5V± 5% |
Current | ≈500 mA |
White Balance | Manual /Auto /a key white balance |
Auto exposure Control | 26μs~20min,Manual/Auto exposure |
Lens Mount | C Mount |
Busy Indicator | LED |
Working temperature | 0℃~60℃ |
Working humidity | 0%-85% |
Spectral response figure:
Really imaging(metallographic analysis):
Packing method | Every single camera is packed with white foam inside, and packed with carton box outside. |
Packing list | 1PC * Camera body 1PC * USB3.0 Card 1PC * USB3.0 Cable 1~3 meter 1PC * CD with software and driver |
Shipping method | FedEx Express/UPS/DHL/TNT, Air mail, Transportation by sea, or others convenient shipping carrier for you. |
Lead time | within 5~7days after payment confirmed |
1.All of our camera come with free software ,and any OEM software you need ,please discuss with us any time !
2.The software function:image capturing,time lapse,measuring,data exporting image mosaic,depth of field overlaying,text instruction inserting,etc.
3.If you have any camera application ,our professional engineer can offer the best solution to you !
4.If you have any target price ,please let us know ,and we will adjust to you if we can do ,as we did not want to lost the good customer like you !
5.We also guarantee the after-sale service time within 24 hours through email, Skype, WhatsApp, phone, or team-viewer.
Notes
Software function | Image capturing, Time lapse, Measuring, Data exporting image mosaic, Depth of field overlaying, Text instruction inserting, etc,. |
Software system | Linux, Windows7, Window8, Window10, Android, etc,. |
Quality warranty | 2 years since you received the goods. |
1.And also we wanted to know if you have any SDK or something for the camera? We need to control the camera via an application.
Answer: Our camera come with free software and SDK,the camera include USB3.0 Card and USB3.0 Cable,Software dis.
2.What is the minimum pcs? 1order OK?
Answer:yes, the minimum order is 1Pc.
3.Whether the quoted prices are Duly packed or not? means includes charges for packing of material before shipping
Answer:sorry that we have not included the freight,and camera price is EXW,it is lowest price.thanks for your kindly understanding in advance.
