Sensor Model | 1/3" CCD Mono |
Sensor Dimension | 4.65μmx4.65μm |
Frame rate | 26fps |
Scan Method | Progressive scan |
Sensibility | 0.4V/lux-sec(550nm) |
Resolution | 30fps@1024x768 |
Shutter | Global shutter |
Dynamic Rate | 61dB |
SNR | 44dB |
Spectral Response | 400nm~700nm |
Data Interface | USB3.0,5Gbps,3M Cable |
Power | DC5V± 5% |
Current | ≈500 mA |
White Balance | Manual /Auto /a key white balance |
Auto exposure Control | 26μs~20min,Manual/Auto exposure |
Lens Mount | C Mount |
Busy Indicator | LED |
Working temperature | 0℃~60℃ |
Working humidity | 0%-85% |
Spectral response figure:
Really imaging:
1.All of our camera come with free software ,and any OEM software you need ,please discuss with us any time !
2.The software function:image capturing,time lapse,measuring,data exporting image mosaic,depth of field overlaying,text instruction inserting,etc.
3.If you have any camera application ,our professional engineer can offer the best solution to you !
4.If you have any target price ,please let us know ,and we will adjust to you if we can do ,as we did not want to lost the good customer like you !
5.We also guarantee the after-sale service time within 24 hours through email, Skype, WhatsApp, phone, or team-viewer.
Notes
Software function | Image capturing, Time lapse, Measuring, Data exporting image mosaic, Depth of field overlaying, Text instruction inserting, etc,. |
Software system | Linux, Windows7, Window8, Window10, Android, etc,. |
Quality warranty | 2 years since you received the goods. |
1.Why you will choose us?
Answer:The company consistently delivers ODM/OEM products that are innovative, easy to integrate, cost-effective and on time. Being a leader of camera designer in China, JPLY is developing to a world class brand. We ensure that customers stay with us over multiple product generations by consistently meeting their demands for cutting edge technology, technical consulting services, integration assistance and the highest manufacturing standards.
2.Delivery time.
Answer:The delivery date within 7 working days after payment confirmed.
3.And is there any case for industry such as LCD or Semiconductor inspection line?
Answer:Yes,our camera can suitable for industry such as LCD or Semiconductor inspection line,and we can recommend the best camera for your reference.
If you want to know more information of our product, please click here,
