Brand New 50CM-18M Infrared range finder wireless ultrasonic rangefinder ranging CP3009 Distance laser measure
Specification:
The ULTRASONIC DISTANCE METER + LASER POINTER is a perfect tool to quickly know the distance, area and volume of a room! It can measure distances in a straight-line from 2 Feet to 60 Feet. Your distance measurer transmits ultrasonic waves to a point you want to measure.
Details Brand new 100%,high quality A unique tool combing latest ultrasonic & laser technologies which allows user to take distance measurement easily. With simple single handed operation, the device can measure, not only distance, but also convert those measurements to square and cube readings automatically. A built-in laser pointer can help to determine user's target.
- Power : 1 x 9V (battery not included)
- Unit of measurement : Feet or Meters
- Accuracy : 0.5% + 1 digit (2 - 60ft)
- Working frequency : 40kHz
- Working temperature : 32F to 109.4F
- Range : 2 to 60 ft (0.55 to 18.288m)
- Dimensions : 2 1/2" x 5" x 2" inches
- Sonic Distance Meter Measure
- Brand new 100%,high quality
- Compact and unique design
- Accurately measures distance from 2 feet to 60 feet
- Calculates area and volume
Features:
Compact and unique design Accurately measures distance from 2 feet to 60 feet Calculates area and volume Laser pointer helps to determine target to be measured Conversion of readings between imperial and metric Ideal for D.I.Y. homeowners, builders, real estate agents and surveyors etc.
- Perfect for realtors, builders, and anyone who needs a measurement or room's area quickly
- Ultrasonic distance measurer With laser point aiming
- Foot/Meter function button
- LCD screen
- Auto stop: Power auto off within 30 seconds;
- Calculation of area and volume.
- Metric or imperial measurement.
- Top and bottom base switch
- With referenced laser point
- Support multiplication
- Support the bottom and top measurement switch
- Support m/ft conversion measurement
- 30 seconds without operating automatic shutdown
- Can detect link temperature
- Can detect the ambient temperature
- Material: ABS
Technical data:
Sensor |
Ultrasonic distance measurer with laser pointer |
Distance measurement |
0.55 - 18.288m (2-60ft) |
used area |
indoors and outdoors |
how to work |
With laser pointer function to determine target to be measured |
Power supply: |
1 x 9V Alkaline type 6LR61 Battery (Not included) |
Units of Measure: |
Feet/Meters |
Accuracy: |
±(0.5%+1 digit) |
Functions: |
Auto power off; Area / volume calculation |
Resolution: |
0.01M or 1/2 Inch |
Frequency: |
40 kHz (ultrasonic pickup) |
Working temperature: |
32°F to 109.4°F (0°C to 43°C) |
Color: |
Black |
Dimensions (H-P-l): |
123X60X39mm |
Weight (without battery): |
108.5g |
Laser beam: |
Wattage 1mW (mW =milliwatt) |
Wavelength: |
650nm (nm =nanometer) |
Certificates: |
CE, ROHS |
Operation steps:
1. Open the on / off switch
2. Press the "READ" button to start. If idle for 30 seconds, it will automatically shut down.
The initial default unit is M, long press "SET" button for 3 seconds to switch between m/ft.
Measurement steps:
1. Press again the "READ" button after starting up, the laser beam is turned on, the distance between the device and the measured point is then displayed on the screen.
2. Place the bottom of the device flat closely on the wall in about the middle position between floor and ceiling. Please ensure that nobarrier between the device and the measured point. and make sure your head or hands do not stand in front of the device.
Set measurement reference:
The initial measurement reference is the tail of the device, and the icon showing tail can be seen on the corresponding screen. If you press the "SET" button, the measurement reference will be transferred to the head, and the icon showing head can be seen on thecorresponding screen.
Notes:
1. Before using the device, please make it adapting to the surrounding environment, so please wait for about 15-30 minutes, and let itsettle to the current room temperature.
2. The measurement results will be displayed for about 30 seconds (or longer if you press other key within 30 seconds).
3. If you try to measure the distance less than 2 feet (0.55 meters) or greater than 60 feet (18 meters), there will be "ERROR" prompt on the screen.
Q:What’s the MOQ ?
Answer: Usually speaking, we do not set MOQ since we want to do business with any business type, including retailer and wholesaler.
Q: How do you deliver the goods ?
Answer: We send by sea or by air including DHL,FedEx,TNT,UPS etc.
Q: What’s you main payment terms ?
Answer: T/T,Paypal ,western union and trade assurance is welcome to us.
Q:Can you do private label ?
Answer: Yes, of course. OEM is absolutely supported; both on package or devices.
Q:What certifications do you have ?
Answer: All electronic products are with CE & RoHS certificates.
Q:How can I get a sample ? What’s the sample fee? Is it refundable ?
Answer: Please confirm with us the model you’ll purchase, and you prepaid the sample fee , after sample tested and qualified, we will refund this sample fee when you place the bulk order. We can send out the sample within 2 working days after receiving payment.
Q:What’s the lead-time ?
Answer: Normally it takes 3-5 working days after receiving payment.
Q:Do you have in stock ?
Answer: Yes, we usually hold some quantities in stock, such as 100pcs or 200pcs are ready to ship immediately.
Q:What about your after-sales services ?
Answer: We have 100% QC before shipment. If there are some unexpected problems happen, we hope to solve these problems with our customers through friendly ways as below:
1, If it’s quality problem, customers must provide photos or videos and other evidences to us for identify. After confirmation, we’ll send the new products to replace the damages in next order.
2, If it’s man-made damaged, customers should take full responsibility.
