1224 cheap used axyz cnc router wood door design machine
Machine Fearture:
1. 9kw air cooled Spindle. (Italy HSD optional)
2. OSAI controller system with handwheel.
3. Linear Guide from Japan.(THK japan optional)
4. High precession ball screw from Germany
5. YASKAWA Serco system ( Option: SIEMENS Servo system)
6. Elsele reducer
7. Drum style auto tool change with 8 positions.
Sutiable Material
Wood, EPS, Gypsum, Industrial wax and many other nonmetal material.
Standard configurations
1.Maximum working size:1800*3100*950mm
A Axis: ±120°
C Axis: ±213°
Maximum work-piece size:
X Axis: 2400mm
Y Axis: 1200mm
2. Z Axis: 900mm (depending on tool length) A Axis: ±120°
3. C Axis: ±213°
4.10KW Italian HSD Spindle
5.Drum style ATC with 8 PCS Positions
6.Table structure: Cast Steel Movable Table
7.OSAI controller system
8.Taper hole in the spindle HS655
9.X, Y, Z Structure: Japan-made THK Guide rail 30
10.TBI ball screw
11.Delta 15kw Inverter from Taiwan
12.YASKAWA Servo system
13.Schneider Electronic spare parts ,
14.Apex reducer from Taiwan
Item |
Description |
Model |
1212/1224/1325 |
X ,Y,Z working area (mm) |
2400*1200*900mm |
C travelling |
±213° |
A travelling |
±120° |
Beam spacing(mm) |
4260 |
Beam Height(mm) |
2150 |
working table |
vacuum table and dust collector |
Spindle |
9kw air cooled spindle and inverter |
Range of speeds |
22000 RPM/min |
Servo Motor brand |
YASKAVA |
Table size (mm) |
1200*2400 |
Product fixed form |
Vacuum table |
Control system |
OSAI |
Machine size |
3600*4000*3500mm |
Total weight |
1800kg |
Voltage |
AC380V/60HZ |
File exchange |
G code |
X,Y axis Maximum speed |
45m/min |
Z,C axis Maximum speed |
20m/min |
A axis Maximum speed |
20m/min |
Guarantee time |
One year of guatantee in case of non-human damage |
Option items: |
Italy spindle |
4 axis spndle
machine body frame
cnc router machine parts | ||
|
Rotary axis |
For engraving on cylindrical shape materials, please kindly tell us your cylindrical shape material’s length and diameter. then we can add right rotary axis to the machine , and quote the right price for your rotary axis. |
|
Vacuum table (contain vacuum pump and vacuum pipes) |
For fixing the material on the working table, especially for bigger working table. |
|
Dust collector(contain dust collector pump and dust collector pipes) |
For sucking away the dusts, such as wood dusts and so on. |
Q: Are you a manufacturer or trading company?
A: We are a Manufacturer and enjoying independent R&D team for 10 years.
Q: Do you have after-sale service team?
A: 24 hours online service for you, via tel/email/video or other way you prefer.
Q: Is there any inspection before delivery?
A: Strict quality examine before delivery, qualified industry related standard requirement.
Q: Can you offer customize manufacture?
A: Customize available based on your demands.
