sesame seeds huller

Specifications

1.sesame seeds huller
2.Wet or Dry Process are optinal
3.Turnkey or EPC
4.China state-owned business.
5.CMEC

sesame seeds huller



1. Wet or Dry sesame hulling process techniques are optional
2. Sesame Hulled rate more than 99%
3. Turnkey and EPC project are accepted
4. China state-owned business guarantee quality
5. CMEC as the project contractor



Sesame peeling process and formula
1.First turn on the sesame screening clean to use
2.The water heated to a certain temperature to use. 50-60°C
3.The good solution diluted into hot water mixing. alkali
4.The sesame again into hot water mixing surface have borne no sesame seeds
5.Soaking for about nine minutes (according to sesame variety)
6.The bubble good out the water, sesame filter clean in peeling machine inside
7.Peeling time about 3-5 minutes completely clean, Don't stop in the add water (easy feeding) open the valve into centrifuges.
8.Seperating the skin and kernel, separating time about 10 minutes or so (note) water pressure the bigger the better.
9.Separation wash good sesame in bag waiting for dehydration drying
10.After drying level to black spots
Model:JXAH-1
Motor power:4.1KW
Net weight:200kg
Dimension:1500*800*1650mm
 Capacity: 150-280kg/h
This machine also has stainless steel one, this picture is carbon steel one.
we could provide various types of blowers for your need!
Sesame peeling machine, sesame peeler
1. APPLICATIONS
Applied for sesame soaking, sesame skin removing, sesame skin and kernel’s separating.
Collect all process together.
2. MECHANICAL STRUCTURES
Mainly include body, composite stirrer, separator, locator, inlets and outlets, and deceleration gear box, etc.
3. OPERATION PRINCIPLES
Soaking
The special stirrer, which is driven by decelerator, puts upward the peripheral sesame seed and the center sesame will continuously move downwards, in this way, the sesame will move up and down, later the sesame soak in water totally.
Skin removing
The stirrer driven by decelerator makes the soaked sesame rotating rapidly up and down.  The hull will removed from the kernel by the friction between sesames and the rotating force from the stirrer.
Skin and Kernel’s Separating
The hull and kernel are pushed continuously by the stirrer driven by decelerator to move in radial and axile directions.  The hull is discharged through the holes on the plate, while the kernel is sustained by the plate with holes, and thus they are separated from each other.

1. Inner packing is vacuum-packed with aluminum foil.
2. Outer packing is fumigation-free wood packages.
3. Suit for long sea transportation

1. Free Install Machine Services to customers' country.
2. Free Teching Services after install
3. Fast quotation response before order

   China Machinery Engineering Corporation (“CMEC”) was built on its predecessor China National Machinery & Equipment Import & Export Corporation through an overall reorganization.  CMEC, first founded in 1978, is the first large engineering & trade company in China, and a member of China National Machinery industry Corporation. The company is a giant business complex engaged in project engineering as the core business, integrating trade, R&D, and international service, and combining technology and trade.



Payment item: 30% Down payment by T/T, and the balance payment by T/T or L/C
Model of Trade: FOB Shanghai or CIF customers' port
Delivery time: 30 work days after get the down payment.
