Help CenterHigh Quality BDM25-63 MCB
Related Products
Specifications
High quality BDM25-63 MCB1. High quality and competitive price
2. Elegant appearance and easy operation
Feature
Protection against both overload and short circuit
High short-circuit capacity
Contact position indication
Applicable to terminal and pin/fork type busbar connection
Easy mounting onto 35mm DIN rail
Technical Data
Rated voltage:AC 230/400V
Rated current(A):1,2,3,4,6,10,13,16,20,25,32,40,50,63
Tripping curve:B,C,D
Ultimate short-circuit capacity(lcu):6KA
Rated frequency:50/60Hz
Energy limiting class:3
Rated impulse withstand voltage:6.2KV
Electro-mechanical endurance:6000
Connection terminal:
Screw terminal
Pillar terminal with clamp
Connection capacity:Rigid conductor up to 25mm2
Fastening torque:2.0Nm
Installation:
On symmetrical DIN rail 35mm
Panel mounting
Terminal Connection Height:19mm
Wenzhou BODUN Electric Co,.Ltd. is one leading manufacturers and exporters of low voltage electrical products and materials in P.R.China. We are OEM. Our major products are series of MCBs, MCCBs, ELCBs,Contactors and Relays.We have always been sticking to the principle of Quality First,Consumers First. Therefore, we established a special quality control department to make sure that our products are loo% qualified. We passed several quality certificates including ISO9001, CE, SEMKO, UL,VDE,FI and so on.
We may not be the best partner you have expected to have, but we are eager to try the best of our ability to become the most reliable partner you are going to have.
If you want to know more information about our company and our products, your are welcome to visit our website: .
