QCIIY-8*3200 Hydraulic Cnc Guillotine Shearing Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Anhui, China
Brand Name:
Hudong
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
QCIIY-hydraulic Cnc Guillotine ShearsNegotiableMOQ: 1 Set -
Steel Sheets Shearing MachineNegotiableMOQ: 1 Set
-
Hydraulic Sheet Metal Guillotine Cutting MachineNegotiableMOQ: 1 Set
-
Hydraulic CNC Guillotine Plate Shearing MachineNegotiableMOQ: 1 Set
-
Hydraulic CNC Guillotine Plate Shearing MachineNegotiableMOQ: 1 Set
Condition
New
Place of Origin
Anhui, China
Brand Name
Hudong
Model Number
QCIIY-E20-8*3200
Dimension(L*W*H)
3870
Certification
CE,ISO9001
Warranty
12 months after saling
After-sales Service Provided
Overseas service center available
Voltage
optional
QCIIY-8*3200 hydraulic cnc guillotine shearing machine
Technical characteristics
1. The frame is steel welded structure, have sufficient strength and rigidity, eliminate internal stress and high frequency vibration, to ensure the overall accuracy of the fuselage. Has a good rigidity, two cylinders fixed on the left and right columns (wallboard).
2. Blades has four sides, every side can be use.
3. E20 NC system control , it digital display , also can simple locate and control back gauge.
4.Hydraulic guillotine shearing machine is second generation shearing machine.
we can adjust shear angle and blade gap. hydraulic swing beam shearing machine just adjust blade gap.
|
Model |
Thickness of sheared plate mm |
Width of sheared plate mm |
Strokes min -1 |
Scope of back stop mm |
Cutting angle ° |
Throat depth mm |
Motor power kw |
Overall dimension mm(L×W×H) |
| 4×2500 | 4 | 2500 | 25-45 | 600 | 0.5-1.5 | 100 | 5.5 | 3000×2000×1850 |
| 6×2500 | 6 | 2500 | 20-45 | 600 | 0.5-1.5 | 125 | 7.5 | 3030×2075×1920 |
| 6×3200 | 6 | 3200 | 16-45 | 600 | 0.5-1.5 | 125 | 7.5 | 3730×2075×1970 |
| 6×4000 | 6 | 4000 | 14-45 | 600 | 0.5-1.5 | 125 | 7.5 | 4530×2075×2080 |
| 6×5000 | 6 | 5000 | 11-40 | 800 | 0.5-1.5 | 125 | 7.5 | 5530×2075×2210 |
| 6×6000 | 6 | 6000 | 9-36 | 800 | 0.5-1.5 | 125 | 11 | 6530×2075×2520 |
| 7×7000 | 7 | 7000 | 7-28 | 800 | 0.5-1.5 | 125 | 11 | 7530×2075×2830 |
| 8×2500 | 8 | 2500 | 20-45 | 600 | 0.5-1.5 | 125 | 11 | 3040×2075×1920 |
| 8×3200 | 8 | 3200 | 16-45 | 600 | 0.5-1.5 | 125 | 11 | 3740×2075×1920 |
| 12×2500 | 12 | 2500 | 12-35 | 800 | 0.5-2 | 125 | 15 | 3110×2575×2210 |
| 12×3200 | 12 | 3200 | 7-35 | 800 | 0.5-2 | 125 | 15 | 3810×2575×2420 |
| 12×4000 | 12 | 4000 | 8-35 | 800 | 0.5-2 | 125 | 15 | 4610×2575×2530 |
| 16×2500 | 16 | 2500 | 16-40 | 800 | 0.5-2.5 | 125 | 22 | 3130×2655×2200 |
| 16×4000 | 16 | 4000 | 12-40 | 800 | 0.5-2.5 | 125 | 22 | 4630×2655×2570 |
| 20×2500 | 20 | 2500 | 16-40 | 800 | 0.5-2.5 | 125 | 30 | 3160×2855×2300 |
| 20×4000 | 20 | 4000 | 12-40 | 800 | 0.5-2.5 | 125 | 30 | 4660×2855×2720 |
| 25×2500 | 25 | 2500 | 8-15 | 800 | 0.5-3.5 | 120 | 37 | 3330×2000×2650 |
| 25×3200 | 25 | 3200 | 8-15 | 800 | 0.5-3.5 | 120 | 37 | 3970×2100×2865 |
| 25×4000 | 25 | 4000 | 6-12 | 1000 | 0.5-3.5 | 120 | 37 | 4780×2500×3150 |
| 32×2500 | 32 | 2500 | 6-12 | 1000 | 0.5-3.5 | 120 | 45 | 4100×2300×3200 |
| 32×3200 | 32 | 3200 | 8-12 | 1000 | 0.5-3.5 | 120 | 55 | 1900×2650×3450 |
| 40×2500 | 40 | 2500 | 4-10 | 1000 | 0.5-3.5 | 120 | 75 | 4100×2550×3500 |
| 40×3200 | 40 | 3200 | 4-10 | 1000 | 0.5-3.5 | 120 | 75 | 4900×2900×3750 |
