sheet metal normal hydraulic press brake 100Tons
Introduction
Adopts steel plate welded structure, with tempering process and vibration aging treatment,
Elimination the working stress and eliminating welding stress caused deformation, ensuring the precision of the machine tool maintenance.
Standard with a multi vee bottom die and punch that is attached to the upper ram with ordinary change punch clamper.
press brake with front support arm
Technical parameter
| Name | Unit | 100T x 3200 |
| Bending force | KN | 1000 |
| worktable length | mm | 3200 |
The distance between two side plates |
mm | 2600 |
Throat Depth |
mm | 300 |
Slider Stroke |
mm | 130 |
Max opening Height between Worktable & slider |
mm | 370 |
Back gauge (X axis) travel range |
mm | 600 |
Approaching Speed |
mm/s | 50 |
Working Speed |
mm/s | 6.5 |
Return Speed |
mm/s | 40 |
Main motor |
kw | 7.5 |
Weight |
kg | 6500 |
Dimension |
mm | 3500x1700x2300 |
Maanshan Hudong Heavy Industry Machiney Manufacturing Co., Ltd. is a specialized company, designated by the nation to produce forging equipment, plate benders, plate shears, press machines and rolling benders, with a production history of more than 30 years.
1. We can send engineers to your factory for your installation ,debugging and training.
2. we can help customer slove problem in the network.
3. welcome to visit our factory, we will pick up.
pls contact Mr Yang, hope to service to you.
| shyzf91(at) | |
| Skype | youth.yang88 |
| 15156701571 |
