Inner tube for shower head

Specifications

Name: rubber hose
Material: 100% EPDM, nature rubber, NBR
Size: 7.5mm--29mm

Newanton can manufacture hoses according to our client's requirements.Capable of direct exchanges with our client designers, we are also able to provide a complete set of design schemes.



To guarantee the quality of the products, we have been awarded a number of certifications including the state CMA Health and Safety (Nontoxic) Standard Certification in 1997, the SGS USA FDA Standard Certification in 1999, ISO 9001:2000 Quality Certification in 2002, USA NSF Certification, RoHS Certification (SGS) in 2006. The standards we practice have all reached or surpassed the following requirements including JG/T187-2006 (China), EN12365 and EN681 (EU), DIN7863, DIN/ISO3302 (Germany) and ASTMC-864-99 (USA).



We have sizes of inner tube for the shower head at present as following.

Number	Material	Inside dia. (mm)	Outside dia. (mm)	Hose ply    (mm)	Length (m)	Pressure (Bar/min)	Hardness (Shore A)
E-70-01	EPDM	6.8±0.10	9.0+0.10	1.1+0.1	200+3	2--3	68--72
E-70-05	EPDM	6.0±0.10	8.2+0.10	1.1+0.1	200+3	2--3	68--72
E-70-06	EPDM	7.2±0.10	9.4+0.10	1.1+0.1	200+3	2--3	68--72
E-70-09	EPDM	7.0±0.10	9.2+0.10	1.1+0.1	200+3	2--3	68--72
E-70-12	EPDM	4.0±0.10	6.2+0.10	1.1+0.1	200+3	2--3	68--72
E-70-15	EPDM	3.0±0.10	5.6+0.10	1.3+0.1	200+3	2--3	68--72
OEM orders are welcome
