NBR gas braided inner hose
Newanton can manufacture hoses according to our client's requirements.Capable of direct exchanges with our client designers, we are also able to provide a complete set of design schemes.
To guarantee the quality of the products, we have been awarded a number of certifications including the state CMA Health and Safety (Nontoxic) Standard Certification in 1997, the SGS USA FDA Standard Certification in 1999, ISO 9001:2000 Quality Certification in 2002, USA NSF Certification, RoHS Certification (SGS) in 2006. The standards we practice have all reached or surpassed the following requirements including JG/T187-2006 (China), EN12365 and EN681 (EU), DIN7863, DIN/ISO3302 (Germany) and ASTMC-864-99 (USA).
We have sizes of Gas braided hose for your reference at present as following.
| Number | Material | Inside dia. (mm) | Outside dia. (mm) | Hose ply (mm) | Length (m) | Pressure (Bar/min) | Hardness (Shore A) |
| N-82-01 | NBR/PVC | 8.0±0.10 | 12.0+0.10 | 2.00+0.1 | 100+3 | 4--6 | 80--83 |
| N-82-05 | NBR/PVC | 8.5±0.10 | 12.0+0.10 | 1.75+0.1 | 100+3 | 4--6 | 80--83 |
| N-82-06 | NBR/PVC | 8.9±0.10 | 12.9+0.10 | 2.00+0.1 | 100+3 | 4--6 | 80--83 |
| N-82-09 | NBR/PVC | 8.3±0.10 | 11.7+0.10 | 1.70+0.1 | 100+3 | 4--6 | 80--83 |
| N-82-12 | NBR/PVC | 8.0±0.10 | 12.5+0.10 | 2.25+0.1 | 100+3 | 4--6 | 80--83 |
| N-82-15 | NBR/PVC | 12.5±0.10 | 17.0+0.10 | 2.25+0.1 | 80+3 | 4--6 | 80--83 |
| OEM orders are welcome | |||||||
