Product Details
Place of Origin: | Zhejiang, China | Brand Name: | Jingkon | Model Number: | 1*3 Plug In FBT Fiber Splitter |
Product Description
Specifications
*1x3 Plug In Module FBT Fiber Splitter*FBT&PLC Fiber Optic Splitter and Coupler
*RoHS,TLC,ISO9001,Telcordia GR-1221
1*3 Plug In Module FBT Optical Fiber Splitter with SC/APC Connector
Main Parameter:
Type | Standard |
Operating wavelength (nm) | 1310 1490 1550 |
Bandwidth (nm) | 1310±40 1490±10 1550±40 |
Coupling ratio (%) | 1~50 |
Typical excess loss(dB) | ≤0.15 |
PDL(dB) | ≤0.10 |
Typical Insertion Loss (dB) | ≤3.6 |
Min directivity(dB) | ≥55 |
Temperature coefficient (dB/) | ≤0.002 |
Operating temperature() | -40~+70 |
Storage temperature() | -40~+85 |
Max operating power (mW) | ≥300 |
Max tensile strength(N) | ≥5 |
Package dimension(mm) | Φ3.0×50 as customer required |
Industry standard bellcore | Telcordia GR-1221-CORE |
Applications:
*FTTX (FTTP, FTTH, FTTN, FTTC)
*Passive Optical Networks (PON)
*Local Area Networks (LAN)
*CATV Systems
*Test Equipments
