Nylon IP68 standard plastic cable gland
USD $0.029 - $0.9
/ Piece
100 Pieces(Min.Order)
- 800000 Piece / Pieces per Month
- Ningbo or Shanghai
- T/T Credit Card
You May Like
-
BNC Strain Relief Boot Black For RG59 Cable
-
ev Car EMC Cable Gland IP68 EMC Elastic Clasping Cable Gland For EV Car Motor And Power
-
IP68 Nickel Plated Copper Cable Gland 4 to 8mm
-
High Quality Hydraulic Breather Vent Valve Big Air Flow Breather Vent Plug Black/Grey Waterproof
-
Air Vent Plug Waterproof For Monitoring Systems Auto Air Vent Exhaust Valve Threaded Plug Made From Plastic Nylon
-
3/8 Inch Hydraulic Breather Vent Plug, M12*1.5 protective screw in vent and waterproof IP68 plastic
Product Details
| Place of Origin: | Zhejiang, China | Brand Name: | OEM or Neutral or Highsail | Model Number: | PG / M / NPT / MG / G |
| Protection Level: | IP68 | Size: | All Size | Material: | Nylon |
Product Description
plastic cable gland
Product Description
| 1.Material | Lock Nut,Main Body,Sealing Nut,Spiral Body,stopper are made from Nylon PA66;Washer and Seal are made from EPDM or Nitrile butadiene rubber(NBR).
|
| 2.Thread Type | PG;M;NPT;MG;G. |
| 3.Size Range | PG7-PG63;M12-M63;NPT3/8''-NPT''11/2'';MG12A-MG63A;G1/4-G3. |
| 4.Thread Length Selection | Long thread type / Short thread type. |
| 5.Fire Rating | UL94V-2;UL94V-0(optional). |
| 6.Authentication | CE;RoHS;SGS. |
| 7.Waterproof Degree | IP68(Thread position with washer). |
| 8.Operating Temperature | Static state from -40°C (-40°F) to 100°C(212 °F), Short-term to 120°C (248 °F). |
| 9.Color | Black and Light Grey(RAL7035) in normal,other colors can be customized. |
| 10.Connection Thread Norms | EN60423 / DIN40430. |
| 11.Mould Feature | Prevent slide design provides superior antivibration protection,ensures a firm grip on the cable. |
| 12.Sample | Free sample for your testing. |
| 13.MOQ | Small order can be accepted. |
| 14.Quality Control | All goods will be 100% inspected before dispatching. |
| 15.Delivery Time | Enough stock and strong production capacity ensure timely delivery. |
| 16.R&D Ability | OEM available,open new molds according to your samples or drawings. |
Technical Parameters
Nylon Cable Gland Technical Parameters(PG&M&NPT&G&MG)
| Item | Cable Range | Main Body | Thread O.D | Thread Length | Item | Cable Range | Main Body | Thread O.D | Thread Length |
| (mm) | H (mm) | AG (mm) | GL (mm) | mm | H (mm) | AG (mm) | GL (mm) | ||
| PG7 | 3-6.5 | 22 | 12.5 | 8 | M12 × 1.5 | 3-6.5 | 22 | 12 | 8 |
| PG9 | 4-8 | 26 | 15.2 | 9 | M16 × 1.5 | 4-8 | 26 | 16 | 9 |
| PG11 | 5-10 | 27 | 18.6 | 9 | M18 × 1.5 | 5-10 | 27 | 18 | 9 |
| PG13.5 | 6-12 | 28 | 20.4 | 9 | M20 × 1.5 | 6-12 | 28 | 20 | 9 |
| PG16 | 10-14 | 30 | 22.5 | 11 | M22 × 1.5 | 10-13 | 30 | 22 | 12 |
| PG19 | 12-15 | 30 | 24 | 11 | M25 × 1.5 | 12-15 | 34 | 25 | 12 |
| PG21 | 13-18 | 34 | 28.3 | 11 | M27 × 1.5 | 13-18 | 35 | 27 | 12 |
| PG25 | 16-21 | 35 | 30 | 12 | M30 × 1.5 | 16-21 | 35 | 30 | 13 |
| PG29 | 18-25 | 40 | 37 | 12 | M32 × 1.5 | 16-21 | 38 | 32 | 13 |
| PG36 | 22-32 | 48 | 47 | 15 | M36× 1.5 | 18-25 | 40 | 36 | 13 |
| PG42 | 32-38 | 49 | 54 | 18 | M40 × 1.5 | 22-32 | 48 | 40 | 18 |
| PG48 | 37-44 | 50 | 59.3 | 18 | M50 × 1.5 | 32-38 | 49 | 50 | 18 |
| PG63 | 42-50 | 60 | 71 | 29 | M63 × 1.5 | 37-44 | 50 | 63 | 18 |
| Item | Cable Range | Main Body | Thread O.D | Thread Length | Item | Cable Range | Main Body | Thread O.D | Thread Length |
| mm | H (mm) | AG (mm) | GL (mm) | (mm) | H (mm) | AG(mm) | GL (mm) | ||
| G1/4 | 3-6.5 | 22 | 13.1 | 8 | NPT3/8" | 4-8 | 26 | 17 | 15 |
| G1/4 | 2-5 | 22 | 13.1 | 8 | NPT3/8" | 2-6 | 26 | 17 | 15 |
| G3/8 | 4-8 | 26 | 16.6 | 15 | NPT1/2" | 6-12 | 30 | 21.2 | 13 |
| G3/8 | 2-6 | 26 | 16.6 | 15 | NPT1/2" | 5-9 | 30 | 21.2 | 13 |
| G1/2 | 6-12 | 30 | 20.9 | 15 | NPT3/4" | 13-18 | 37 | 26.2 | 15 |
| G1/2 | 5-9 | 30 | 20.9 | 15 | NPT3/4" | 9-16 | 37 | 26.2 | 15 |
| G3/4 | 13-18 | 37 | 26.4 | 15 | NPT1" | 18-25 | 40 | 33.3 | 16 |
| G3/4 | 9-16 | 37 | 26.4 | 15 | NPT1" | 13-20 | 40 | 33.3 | 16 |
| G1 | 18-25 | 40 | 33.2 | 16 | |||||
| G1 | 13-20 | 40 | 33.2 | 16 |
| Item | Cable Range | Thread O.D | Thread Length | Item | Cable Range | Thread O.D | Thread Length |
| (mm) | AG(mm) | GL(mm) | (mm) | AG(mm) | GL(mm) | ||
| MG12A | 3-5.2 | 12 | 9 | MG32A | 15-22 | 32 | 15 |
| MG12A | 4.5-8 | 12 | 9 | MG32A | 18-25 | 32 | 15 |
| MG16A | 4-7 | 16 | 15 | MG40A | 20-25 | 40 | 20 |
| MG16A | 6-10 | 16 | 15 | MG40A | 24-30 | 40 | 20 |
| MG20A | 6-11 | 20 | 15 | MG50A | 26-32 | 50 | 23 |
| MG20A | 9-14 | 20 | 15 | MG50A | 30-40 | 50 | 23 |
| MG25A | 10-16 | 25 | 15 | MG63A | 38-46 | 63 | 24 |
| MG25A | 13-18 | 25 | 15 | MG63A | 40-50 | 63 | 24 |
Strain Relief Cable Gland Technical Parameters(PG&M&NPT&G&MG)
| Item | Cable Range | Thread O.D | Thread Length | Main Body | Inner Diameter |
| (mm) | AG (mm) | GL(mm) | H(mm) | d(mm) | |
| PG7 | 3-6.5 | 12.5 | 8 | 60 | 7.5 |
| PG9 | 4-8 | 15.2 | 8 | 70 | 9 |
| PG11 | 5-10 | 18.6 | 10 | 80 | 11 |
| PG13.5 | 6-12 | 20.4 | 10 | 90 | 13 |
| PG16 | 10-14 | 22.5 | 12 | 98 | 15.8 |
| PG21 | 13-18 | 28.3 | 12 | 108 | 19.8 |
| M12 × 1.5 | 3-6.5 | 12 | 8 | 60 | 7.5 |
| M16 × 1.5 | 4-8 | 16 | 8 | 70 | 9 |
| M18 × 1.5 | 5-10 | 18 | 10 | 80 | 11 |
| M20 × 1.5 | 6-12 | 20 | 10 | 90 | 13 |
| M22 × 1.5 | 10-14 | 22 | 12 | 98 | 15.8 |
| M25 × 1.5 | 13-18 | 25 | 12 | 108 | 19.8 |
| M27 × 1.5 | 13-18 | 27 | 12 | 108 | 20 |
Thread Plug / Stopper Technical Parameters(PG&M)
| Item | Thread O.D | Thread Length | Main Body Dimension | Cover Dimensions |
| AG(mm) | GL(mm) | H(mm) | D (mm) | |
| PG7 | 12.5 | 5 | 8 | 14 |
| PG9 | 15.2 | 6 | 9 | 17 |
| PG11 | 18.6 | 6 | 9 | 20 |
| PG13.5 | 20.4 | 6.5 | 9.5 | 22 |
| PG16 | 22.5 | 6.5 | 9.5 | 24 |
| PG21 | 28.3 | 7 | 11 | 30 |
| PG29 | 37 | 8 | 12 | 39 |
| PG36 | 47 | 9 | 15 | 50 |
| PG42 | 54 | 10 | 16 | 57 |
| PG48 | 59.3 | 10 | 16 | 64 |
| M12x1.5 | 12 | 5 | 8 | 14 |
| M16x1.5 | 16 | 6 | 9 | 17 |
| M18x1.5 | 18 | 6 | 9 | 20 |
| M20x1.5 | 20 | 6.5 | 9.5 | 22 |
| M22x1.5 | 22 | 6.5 | 9.5 | 24 |
| M24x1.5 | 24 | 6.5 | 10 | 27 |
| M25x1.5 | 25 | 6.5 | 10 | 27 |
| M30x1.5 | 30 | 6.5 | 10 | 33 |
| M32x1.5 | 32 | 8 | 11 | 35 |
| M36x1.5 | 36 | 8 | 12 | 39 |
| M40x1.5 | 40 | 8 | 13 | 43 |
| M50x1.5 | 50 | 9 | 15 | 55 |
| M54x1.5 | 54 | 10 | 16 | 57 |
| M60x1.5 | 60 | 10 | 16 | 64 |
| M63x1.5 | 63 | 10 | 16 | 66 |
Packaging & Shipping
| 1.Packaging | (1)Interior Packaging:10/20/50/100pcs per polybag with neutral label or customized (2)External Carton:44*43*36cm;52*33*48cm;42*36*25cm;37*26.5*18.5cm or customized |
| 2.Transportation | (1)By sea,by air,or by express(TNT,Fedex,UPS,DHL,Aramex,EMS etc); (2)We will do best to get good freight cost for you. |
| 3.Payment Terms | T/T, Paypal,Western Union,L/C,Escow |
| 4.Delivery Time | 10 days within 100000pcs.According to your order quantity. |
| 5.Company Type | Factory and trade integration,years of export experience; |
