Conveyor Belt Heat Treatment Oven for Hardening tempering bolt nut
- 100 Set / Sets per Month
- SHANGHAI
- Credit Card
Product Details
Condition: | New | Type: | Resistance Furnace | Usage: | Muffle Furnace |
Place of Origin: | Zhejiang, China | Brand Name: | Huahong | Model Number: | RCW |
Voltage: | 380V | Power(W): | 45-150 | Dimension(L*W*H): | 2400*220*50 |
Weight: | 10-23ton | Certification: | ISO9001:2008 | Warranty: | 1year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Product introduction:
Suitable for bulk small and medium mechanical parts such as( standard self-tapping screw bearing chain textile hardware hand tools play mat ect.)
In a controlled atmosphere carburizing and carbonitriding quenching heat treatment, etc
Performance characteristics:
The temperature is evenness,use whole fibers liner more save plete control system safe and convinced. Deserve to go up the clearing machine tempering furnace feeder form an Automatic production line.
1.RCW mesh belt quenching furnace parameter
model | work size(mm) | rate power (KW) | capacity Kg/H | ||
quenching | carburizing 0.1-0.2(mm) | carbonitriding | |||
RCW-20 | 1300×150×50 | 20 | 30 | 15 | 10 |
RCW-45 | 2400×220×50 | 45 | 60 | 30 | 20 |
RCW-60 | 2400×300×50 | 60 | 100 | 40 | 60 |
RCW-75 | 3600×300×50 | 75 | 150 | 60 | 45 |
RCW-90 | 4700×300×80 | 90 | 200 | 90 | 60 |
RCW-120 | 4700×400×80 | 120 | 150 | 120 | 90 |
RCW-150 | 5000×500×80 | 150 | 300 | 150 | 120 |
2.RCW mesh belt tempering furnace parameter
model | rate power (KW) | max capacity(kg/h) | tate temperature°C) | work size(mm) |
RCW-25 | 25 | 40 | 600 | 3000×400×120 |
RCW-35 | 35 | 60 | 600 | 4000×400×120 |
RCW-45 | 45 | 150 | 600 | 3900×600×120 |
RCW-60 | 60 | 200 | 600 | 5000×600×120 |
RCW-90 | 90 | 300 | 600 | 4700×800×120 |
RCW-90 | 90 | 300 | 600 | 6000×600×20 |
3.pictures show:
our factory:
our certificate:
