Home > Products > MPS > MPS MP2617AGL MP2617A 2617AGL 2617A 3A Switching Charger with NVDC Power Path Management For Single Cell Li+ Battery
MPS MP2617AGL MP2617A 2617AGL 2617A 3A Switching Charger with NVDC Power Path Management For Single Cell Li+ Battery
- 2000 Piece / Pieces per Month
- SZ/HK
- Credit Card PayPal
Product Details
D/C: | 10+ | Package: | QFN | Model Number: | MP2617A |
Type: | Drive IC | Brand Name: | MPS | Place of Origin: | Taiwan |
Product Description
The MP2617A and MP2617B is a monolithic switch mode battery charger with power path management for single-cell Li-ion batteries in a wide range of tablet and other portable devices. It integrates a synchronous BUCK regulator to provide regulated voltage for powering the system output and at the same time charging the battery. This device supports both USB and high power DC adapter input. In USB mode, the input current limit can be programmed to 450mA or 825mA via the logic pins to cover the USB2.0 and USB3.0 specifications. When the adapter input is present, the input current can also be limited in order to avoid overloading of the DC adapter. Input current limit can be programmed up to 3A.
The smart power path management allows MP2617A and MP2617B to regulate the system voltage for powering an external load and charging the battery independently and simultaneously. This allows immediate system operation even under missing or deeply discharged battery. When the input current limit is reached, the system load is satisfied in priority, then the charger will take the remaining current to charge the battery. Additionally, the smart power path control allows an internal connection from battery to the system in order to supplement additional power to the load in the event the system power demand increases over the input limited power or the input is removed.
The MP2617A and MP2617B features high integration with all the power switches included inside. No external MOSFET, blocking diodes, or current sense resistor is required.
Two status monitor output pins are provided to indicate the battery charge status and power source status. Other features include trickle charge, battery temperature monitoring, timer and thermal limiting regulation on chip.
The MP261A and MP2617B is available in QFN 3mmx4mm package.
Accepts wire transfer, Western union, Paypal and Moneygram.
All items are priced each.
All items are subject to availability and passing our QA inspection.
Packaging: Safety package(Carton)
Shipping:
1. We will ship the items within 2 working days after the payment confirmed.
2. We can ship to you by UPS/DHL/TNT/EMS/FedEx/HK post/china post. Please contact us directly and we will use your preferred ways. For the Countries & Regions where EMS cannot deliver, please choose other shipping ways.
Warranty:
1.Our side always double check all the products before delivery to make sure correct.
2.All components we sell has 30 days return policy from the day of shipment, but if the damage is man-made, we will be unable to change for you.
