Specifications
1.vertical ring die wood pellet mill:1-1.5t/h2.make pellet:6-8mm
3.auto-lubricate oil,hydraulic pressure pump
4.90kw
5.CE
Vertical ring die wood pellet mill application:
Our XGJ series vertical ring die wood pellet mill can press low shaping and low adhesiveness raw material in to 6-8mm pellet, such as all kinds of wood sawdust, rice husk, peanut shell, sunflower seed shell, bamboo, rind bagasse, palm etc.
Vertical ring die wood pellet mill note:
Before making biomass pellets, raw material need to crush into fine powder. Raw material moisture should be better between 10-15%.
Vertical ring die wood pellet mill characteristics:
1. Vertical ring die wood pellet mill with vertical ring die, can feeding vertically; no arching of raw material, easy for heating dissipation.
2. Vertical ring die wood pellet mill ring die fixed, rollers rotating, materials centrifugal, evenly distributed around.
3. Vertical ring die wood pellet mill has double-layer dies, up and down dual-use, high efficiency, saving energy. The die are made by stainless stall, which guarantee the die with long lifetime.
4. Vertical ring die wood pellet mill with independent lubrication system lubricate the rollers and shaft, ensure the machine stable working for long time; high pressure filtration, clean the dust and unblocked.
5. Vertical ring die wood pellet mill equip with air cooling system, keep the pelleting room with constant temperature, reduce the grease overflow or carbon agglomerate cause by pellet machine part high temperature, thus guarantee the lubrication system working normally. Meanwhile will collect the dust.
6. Vertical ring die wood pellet mill weight is 5.3ton, can keep the machine working stable when operation.
7. Vertical ring die wood pellet mill adopt gear drive, reduce the loss of Kinetic energy.
8. Vertical ring die wood pellet mill can equip with changeable speed feeder, feeding uniform, assure the pelleting ratio.
9. Vertical ring die wood pellet mill can equip with conditioner, which can adjust the moisture of raw material, assure the last pellets with good smooth.
10. Vertical ring die wood pellet mill is our Nation Patent Product, which admitted by China State Intellectual Property Office. Each part are made by our selves except motor.
Vertical ring die wood pellet mill technical parameter:
Model |
Capacity (t/h) |
Power (kw) |
Specification (mm) |
Weight (t) |
XGJ560 |
1-1.5 |
90 |
6-8 |
5.3 |
XGJ720 |
1.5-2.5 |
160 |
6-8 |
9.5 |
XGJ850 |
2.5-3 |
220 |
6-8 |
14.2 |
XGJ920 |
3-4.5 |
315 |
6-8 |
18 |
XGJ1050 |
4.5-6 |
415 |
6-8 |
24.5 |
