Feed Pellet Cooling Machine

Feed Pellet Cooling Machine photo-1
US$ 1 - 299,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
Yulong
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Shandong, China
Brand Name Yulong
Model Number SKLN1.5
Type Other, Feed Pellet Machine, Buckets, Coolers & Holders
Voltage 380v
Power(W) 0.25kw
Weight 900 kg
Certification CE, ISO, CE / EU, SGS
Warranty 13months
After-sales Service Provided Engineers available to service machinery overseas

1.feed pellet cooling machine cooler  is mainly to cool 2to8mm diameter pellets, when outlet from pellet machines,the temperature is about 60to80 centigrade, after cooler, the temperature is not higher than room temperature +3-5.



2.feed pellet cooling machine  cooler adopts counter flow theorycold air goes to cooler

from bottom to top, hot pellets goes to cooler from top to bottom, as time goes on, pellets will pile up at the cooler bottom, cold air will cool pellets at the bottom gradually, in this way will reduce pellet broken situation , if cold air also go to cooler from top, which same as pellets flowing direction, then hot pellets will meet with cold air suddenly , pellets will be easily broken, especially pellets surface. In this way can cool fully and equally, pellet broken rate is smaller than 0.2%.



3.feed pellet cooling machine cooler  generally works with cyclone and air fan, air lock.

which is used to absorb cold air and clean dust, also it can install a screener at the cooler bottom, which can separate powder dust and good pellets



4.feed pellet cooling machine cooler is hot selling more than 20000 sets per year , greatly welcome to ask me for details., we have big discount at this moment



Model

SKLN1.2

SKLN1.5

SKLN2.5

SKLN4

SKLN6

SKLN8

SKLN10

Output(t/h)

0.8-1.2T/h

1-2/h

3-5T/h

5-8T/h

8-12T/h

12-15T/h

15-20T/h

Capacity (CBM)

1.2

1.5

2.5

4

6

8

10

Cooling Time

Not less than 10 minutes

Cooled Temp (°C)

Room temperature + 3-5°C

Power (kw)

0.18

0.25

0.37

0.37

0.37

0.37

0.37×2

Wind Pressure

Higher than 200mm H2O

Power of Fan(kw)

5.5kw

7.5kw

11kw

18.5kw

22kw

30kw

37kw
