Help CenterSB 38 CNC Pipe Bneding Machine
Related Products
Specifications
SB38CNC-4A-2S CNC pipe bending machine1. Mitsubishi servo motor
2. Mitsubishi PLC
3. Yuken Valve
4. Schneider electri
1. Automatic recognition of power in machine and work piece, the processing is both quick and good
2. Slow returning core, boosted by barrow, imporving the apprearance of the angle.
3. The whole operation is in the computer, simple, quick and correct
4. Picturized programming system: draw and modify on the stereo pipe image on the screen, makes the operation simple, quick and correct
5. Rebound test: comparison test on the features of lots of pipe materials
6. Single-step debugging function- a careful observe on the deformation of the pipe material during the trail manufacture of dies.
7. Automatic drawing of the graphics of dies-clear help to develop new products
8. Over-all inspection: hydraulic/electrical circuit/ driving systems, adsence of phase in motors/inversion, voltage, temperature, oil pressure, and automatically diagnose the troubles
9. Passwords, keys, working hours/ recordings of quantities, are applied to management of production
| Specification/Model | SB-38CNC | Remark | |
| Max bending capability | Φ38mmx2.0mm |
1. The Minimum bending diameter of CNC bending machine based on the pipe diameter 2.The Max bending diameter of CNC bending machine can accordingto the customers requirement 3.The Max length of mandrel of CNC bending machine can according to customers requirement |
|
| Max bending radius | R200mm | ||
| Min bending radius | 1.5 times OD | ||
| Max bending angle | 190° | ||
| Max feeding length | 2500mm | ||
| feeding method | direct feeding clamping feeding |
||
| Working speed | Bending speed | Max 85°/s | |
| Rotary speed | Max 200°/s | ||
| Feeding speed | Max 1000mm/s | ||
| Working accuracy | Bending accuracy | ±0.1° | |
| Rotary accuracy | ±0.1° | ||
| Feeding accuracy | ±0.1mm | ||
| Information inputting method | 1. axisX . Y. Z ing valueY. B. C |
||
| Bending method | 1.Servo bending : 5kw(more than 3 axis 2. Hydraulic bending |
||
| Power of rotary servo motor | 0.75kw | ||
| Power of feeding servo motor | 1kw | ||
| Max bending groups | 1. 12 2. 33 |
||
| Max storing components | 1. 330 2. 125 |
||
| Motor power | 5.5kw | ||
| Oil pressure | 12 Mpa | ||
| Size | 4250 x 900 x 1250mm | ||
| Weight | 1800kg | ||
| Packaging Details: | This CNC Pipe Bending Machine Packed in Iron Case |
|---|---|
| Delivery Detail: | This CNC Pipe Bending Machine Delivery Time is 18 Days |
