Specifications
1.EMA3020 glass cutting water jetposed with CNC cutting table
3.HP system
4.CAD/CAM software system
5.cutting head
EMA3020 glass cutting water jet
CNC water-jet cutting machine is composed with cutting table, HP pump, CNC control system with cutting software, cutting head, Hp water valve, and sand controlling system. Also you can choose optional systems such as auto abrasive feeding system, water softening system and oil cooling system according your requests.
1. Cutting table
- structure:Bridge
- cutting area
- X-axis:1000mm
- Y-axis:1000mm
- Z-axis:150mm
- repeatability:0.05mm
- X,Y speed:0-15m/min
- cutting accuracy:±0.1mm
power:220VAC, 60Hz, 3 phase 4 wire system (can be customized)
Remark: color can be made by customer ‘s requirement.
2. Abrasive cutting system
3.HP system
4. PCIMC-6A special software
5. EMM-A auto abrasive feeding system(option item)
6. EMM cooling system(optional item)
7. EMM- water soften system (optional item)
No. |
Name |
Model |
Specification |
Remark |
1 |
EMA3020 CNC water jet (Bridge) |
EMA3020 (H2O) |
Max. pressure: 380MPA |
Standard |
EMA3020 cutting table |
Cutting size: 3.0m*2.0m |
Standard |
||
EMM CNC control system |
Based on Windows with NC studio |
Standard |
||
2 |
Auto abrasive feeding system |
100L |
N/A |
optional |
3 |
Auto abrasive feeding system |
170L |
N/A |
optional |
4 |
Cooling system A |
|
N/A |
optional |
5. |
Cooling system B |
TCO-10A/1D |
N/A |
optional |
6. |
water soften system |
EMM-2000 |
2T/h |
optional |
7 |
Hand-hold controller |
N/A |
NAIKY |
optional |
8 |
Tools &Spare parts |
List 1&List 2 |
Free with the machine |
free |
9 |
Optional parts |
List 3 |
N/A |
optional |
