MG82 Tool and Cutter Grinding Machine

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Surface Grinding Machine

CNC or Not:

Normal

Extreme Machinery Manufacture Co., Ltd. (Jingjiang)

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Surface Grinding Machine

CNC or Not Normal

Max. Grinding Length 530mm

Place of Origin Jiangsu, China

Brand Name EMM

Model Number MG82

Voltage 380V

Power(W) 0.4kw

Dimension(L*W*H) 1140*1630*1960mm

Weight 0.89kg

Certification ISO

After-sales Service Provided Engineers available to service machinery overseas

Specifications

MG82 tool and cutter grinding machine/Precision Surface Grinder machine. All the Surface grinding series which adopt the V-type

MG82 tool and cutter grinding machine

Technical data of MG82:

piece to be Ground ( L×W×H)			mm	520×220×490
Max. Grinding Length			mm	530
Max. Grinding Width			mm	220
Distance From Table Surface To Spindle Center			mm	490
Slide way				V-type rail with Steel-ball
V-type rail with Steel-ball			Kg	200
Table Size (L×W)			mm	480×200
Number of T -Slot			mm×n	12×1
Speed OF Working Table			m/min	3-23
Cross Feed On Handwheel			mm	0.02/Graduation 2.5/revolution
Vertical Feed On Handwheel			mm	0.01/Graduation 1.25/revolution
Wheel Size (dia.×width×bore )			mm	200×16×31.75
Spindle Speeds	50Hz	rpm		2850
				30-6000
Spindle Motor			Kw	1.1
Hydraulic station motor			Kw	1.5
Working Pressure			Mpa	3
Max.Capacity			L/min	18
Minimum Of Numerical			L	80
Coolant Pump			Kw	0.4
Minimum of Numerical Display			mm	0.001-0.005
Machine Size (L×W×H)			mm	1680×1140×1800
Packing Size (L×W×H)			mm	1140×1630×1960
Gross,Net			T	O.89, 0.79
