QC12K-8x4000 CNC hydraulic sheet metal steel plate cutting
QC12K-8x4000 CNC hydraulic sheet metal steel plate cutting
1.The QC11Y cnc metal sheet guillotine shearing machine is entirely welded and treated with fireplace tempering.
2.It adopts the hydraulic gearing and the energy accumulator for return stroke.
3.The rolling guide with three-point support facilitates to improve the cutting quality.
4.The rectangular balance comes with 4 usable balance angles and has a long service life.
5.The adjustment of blade angles complies with the indicator,fast and convenient.
6.A beam alignment device is configured,which also can adjust the stroke of upper tool post in stepless mode.
7.The fence-type safety protection device is adopted by the QC11Y/K hydraulic guillotine shearing machine.
8.The back gauge dimension and cutting times are available in digital display.
9.The cutting angle is adjustable.
10.The QC11Y adopt Estun E21 system.
11.The OC11K-NC cnc metal sheet guillotine shearing machine is equipped with Estun E200 control system.
12.The QC11K-CNC cnc metal sheet guillotine shearing machine is applicable for plate cutting due to its adoption of DELEM DAC310/DAC360 CNC control system by Netherlands.Its back gauge adopts imported ball screw and liner guideway.
| Shearing thickness | Shearing width | Number of stroke mm | Backgauge range mm | Shearing angler | Backgauge range mm | Motor power KW | |
| 6x2500 | 6 | 2500 | 16~35 | 20-600 | 30’-1°30 | 600 | 7.5 |
| 6x3200 | 6 | 3200 | 14~35 | 20-600 | 30’-1°30 | 600 | 7.5 |
| 6x4000 | 6 | 4000 | 10~30 | 20-600 | 30’-1°30 | 600 | 7.5 |
| 6x5000 | 6 | 5000 | 10~30 | 20-800 | 30’-1°30 | 800 | 11 |
| 6x6000 | 6 | 6000 | 8~25 | 20-800 | 30’-1°30 | 800 | 11 |
| 8x2500 | 8 | 2500 | 14~30 | 20-600 | 30’-1°30 | 600 | 11 |
| 8x3200 | 8 | 3200 | 12~30 | 20-600 | 30’-2° | 600 | 11 |
| 8x4000 | 8 | 4000 | 10~25 | 20-600 | 30’-2° | 600 | 11 |
| 8x5000 | 8 | 5000 | 10~25 | 20-800 | 30’-2° | 800 | 15 |
| 8x6000 | 8 | 6000 | 8~20 | 20-800 | 30’-2° | 800 | 15 |
| 12x2500 | 12 | 2500 | 12~25 | 20-800 | 30’-2° | 800 | 15 |
| 12x3200 | 12 | 3200 | 12~25 | 20-800 | 30’-2° | 800 | 15 |
| 12x4000 | 12 | 4000 | 8~20 | 20-800 | 30’-2° | 800 | 15 |
| 12x5000 | 12 | 5000 | 8~20 | 20-800 | 30’-2° | 800 | 22 |
| 12x6000 | 12 | 6000 | 6~20 | 20-1000 | 30’-2° | 1000 | 30 |
| 16x2500 | 12 | 2500 | 12~20 | 20-800 | 30’-1°30 | 800 | 22 |
| 16x3200 | 16 | 3200 | 12~20 | 20-800 | 30’-1°30 | 800 | 22 |
| 16x4000 | 16 | 4000 | 8~15 | 20-800 | 30’-1°30 | 800 | 22 |
| 16x5000 | 16 | 5000 | 8~15 | 20-1000 | 30’-1°30 | 1000 | 30 |
| 16x6000 | 16 | 6000 | 6~15 | 20-1000 | 30’-1°30 | 1000 | 37 |
| 20x2500 | 20 | 2500 | 10~20 | 20-800 | 30’-3° | 800 | 30 |
| 20x3200 | 20 | 3200 | 10~20 | 20-800 | 30’-3° | 800 | 30 |
Provide Pre-sales Consultant & On-purchase service 8 hr × 6 days per week
1. Reply within 24 hours
2. Provide relevant product information
3. Answer question of customer's requirement
4. Give technical suggestion
Provide After-sales service 24hr × 7days per week
1. Test the machine before shipment
2. Provide technical guidance relate to use the machine
3. Supply one-year warranty period for the machine
4. Provide the spare parts at cost price after warranty period
5. Collect the feedback for the machine working
6. Provide long-term technical assistance.
EMM’s is a comprehensive enterprise dealing economic and technology cooperation that specializes in manufacturing for metal fabrications and distributing of all types of machinery tools Including Industrial Equipment, fabricating equipment, sheet metal equipment and production line machinery.
We are not only trading with customers from domestic and oversea but also providing customers with technical, commutation and after sales support.
Our dedication to the highest quality products and services have establish excellent trade relations with customers from all over the world. EMM’s team memebers includes qualified sales specialists and highly trained technical professional to help provide quick service and the best quality of work in order to meet our customer needs.
QC12K-8x4000 CNC hydraulic sheet metal steel plate cutting
1. 100% by T/T;
2. 30% deposit by T/T, the balance paid by L/C at sight;
3. 100% by L/C at sight;
4. 100% by 30, 60 or 90 days usance credit.
